Charbroil Designer 463261006 Grill Parts

Char-Broil Designer Series Stainless 3-Burner Dual-Fuel gas BBQ grill with side burner

Highest quality replacement parts for your Charbroil Designer 463261006 - Free USA shipping $49 or more* - No Sales Tax*

Charbroil 463261006 owners manual and diagrams

Diagrams & owners manual not available for grill model# 463261006. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Replacement grill parts for the Charbroil Designer 463261006

On this page you'll find all of the parts that fit model Charbroil 463261006. If the part you're shopping for isn't included below, you might find it using the category buttons on the right side of the page. For example, if your looking for a warming rack and there are none here, click the warming rack button to see all of the racks we have for Charbroil grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Charbroil 463261006 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Charbroil model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

463261006 Burners

Click for photos

Stainless steel burner for Charbroil model 463261006. Includes screw in venturi for adjusting air flow.

Part Number: 15591 (Replaces Charbroil 80005703)
Dimensions: 15 7/8” x 1”
Material: stainless steel
Weight: 0.8

==> All Charbroil Burners.

463261006 Cooking Grids

Click for photos

Cast iron cooking grids for Charbroil model 463261006. SET OF TWO (2) panels.

Porcelain treated, matte finish
Each panel measures 18 1/4” x 13 1/8”
Overall dimensions: 18 1/4” x 26 1/4”

Part Number: CG-65P-CI-X2 (Replaces Charbroil 80005724)
Dimension Front-to-Back: 18 1/4”
Dimension Side-to-Side: 26 1/4”
Material: cast iron
Weight: 18.8

Click for photos

Reversible, heavy cast iron cooking grids for Charbroil model 463261006. Porcelain treated, flat matte finish. SOLD INDIVIDUALLY

Part Number: 66652-1PC
Dimension Front-to-Back: 18 1/4”
Dimension Side-to-Side: 13 1/8”
Material: matte cast iron
Weight: 10.0

Click for photos

Cast iron cooking grid for Charbroil model 463261006. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-65P-CI
Dimension Front-to-Back: 18 1/4”
Dimension Side-to-Side: 13 1/8”
Material: cast iron
Weight: 9.4

==> All Charbroil Cooking Grids.

463261006 Heat Plates

Click for photos

SET OF FOUR/4 PACK Flame Tamer, stainless steel for Charbroil model 463261006. Made in USA.

NOTE: Sometimes shipped with protective vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0141-X4
Dimension Front-to-Back: 16”
Dimension Side-to-Side: 3 3/4”
Material: stainless steel
Weight: 3.92

Click for photos

Stainless steel heat plate/Flame Tamer for Charbroil model 463261006.

Part Number: CBHP2 (Replaces Charbroil 80003332)
Dimension Front-to-Back: 16”
Dimension Side-to-Side: 3 3/4”
Material: stainless steel
Weight: 0.7

==> All Charbroil Heat Plates.

463261006 Igniter Components

Click for photos

Burner mounted electrode for use with 15591 and 15491 burners.

39” wire with female spade connector
Includes adapter wire part 03198 for applications needing male spade connector on electrode.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 04430
Material: ceramic
Weight: 0.1

==> All Charbroil Igniter Components.

463261006 Heat indicators and Meat Thermometers

Click for photos

Semi-circular, snap in heat indicator with 2 3/4” heat prob.

Part Number: 00473 (Replaces Charbroil 80004030)
Dimensions: 1 3/4” x 1 3/16”
Material: stainless steel
Weight: 0.1

==> All Charbroil Heat indicators and Meat Thermometers.

463261006 Accessories

Click for photos

Cast iron smoker box with six oblong venting holes. Designed to release wood smoke. Make sure this part will fit into your grill before ordering 8 3/8” x 5 1/4” x 1 3/8”.

Part Number: 00150
Dimensions: 5 1/4” x 8 3/8”
Material: cast iron
Weight: 3.90

Click for photos

Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

Click for photos

Chrome plated rib/potatoe rack. Spaces up to 6 racks of ribs and 6 potatoes. Fits all grills. 12” x 7 1/4”.

Part Number: RR-2
Material: chrome steel
Weight: 1.0

Click for photos

Venturi Tube 12” Brush. Recommended by all grill manufacturers. Specially designed flexible brush to clean venturis of spider webs and other obstructions that can cause flashback fires. Stainless steel.

Part Number: VTC-B
Material: stainless steel
Weight: 0.3

==> All 463261006 Accessories.
