Charbroil Designer 463260107 Grill Parts

Charbroil logo



Charbroil 463260107

Char-Broil Designer Series Stainless 4-Burner Dual-Fuel gas BBQ grill with side burner



Highest quality replacement parts for your Charbroil Designer 463260107 - Free USA shipping $49 or more* - No Sales Tax*



Charbroil 463260107 owners manual and diagrams
Click the small images on the right to view Charbroil 463260107 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!



Charbroil 463260107-463543989230-PartsExpS1.jpg

Replacement BBQ grill parts for Charbroil Designer 463260107
On this page you'll find all of the parts that fit model Charbroil 463260107. If you can't find the part you need below, click on the appropriate category button on the right side of the page. For example, if your looking for a cooking grid and there are none here, click the cooking grids button to see all of the cooking grids we have for Charbroil grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Charbroil 463260107 BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Charbroil model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



463260107 Burners

80005703 / 15591
Click for photos
Stainless steel burner for Charbroil model 463260107. Includes screw in venturi for adjusting air flow.

Part Number: 15591 (Replaces Charbroil 80005703)
Dimensions: 15 7/8” x 1”
Material: stainless steel
Weight: 0.8

$34.77

Qty


==> All Charbroil Burners.






463260107 Burner Brackets and Carryovers

80006583 / CBCO1
Click for photos
Stainless steel cross over tube. Channels gas between burners.

Part Number: CBCO1 (Replaces Charbroil 80006583)
Dimensions: 7
Material: stainless steel
Weight: 0.05

$15.90

Qty


==> All Charbroil Burner Brackets and Carryovers.






463260107 Cooking Grids

CG-DUMMY
Cooking grid not known for Charbroil model 463260107. Our parts information for this grill model is incomplete, and we really don't know with certainty which cooking grid fits this model. It may be that we have the part but don't show it here due to data or other error.

If you know the original OEM part number, try searching for it in the search box at the top of this page.

You can also browse through all of the Charbroil cooking grids we carry. If we don't have the exact fit grid for your grill, we may have a suitable replacement part. Measure your existing part as well as the the grid support area of the grill so you'll know exactly what size grids will fit.

If you have this grill model and know the number and dimensions of your original cooking grids, please share this information with us. Click here to send an email to our GrillDr that includes this information. We greatly appreciate your help.

Part Number: CG-DUMMY
Weight: 1.0
==> All Charbroil Cooking Grids.






463260107 Heat Plates

CLA-TS0141-X4
Click for photos
SET OF FOUR/4 PACK Flame Tamer, stainless steel for Charbroil model 463260107. Made in USA.

NOTE: Sometimes shipped with protective vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0141-X4
Dimension Front-to-Back: 16”
Dimension Side-to-Side: 3 3/4”
Material: stainless steel
Weight: 3.92

$56.88

Qty


80003332 / CBHP2
Click for photos
Stainless steel heat plate/Flame Tamer for Charbroil model 463260107.

Part Number: CBHP2 (Replaces Charbroil 80003332)
Dimension Front-to-Back: 16”
Dimension Side-to-Side: 3 3/4”
Material: stainless steel
Weight: 0.7

$21.87

Qty


==> All Charbroil Heat Plates.






463260107 Igniter Components

IG-30B
Click for photos
46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-30B
Dimensions: 46
Weight: 0.1

$7.10

Qty


IG-48B
Click for photos
16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-48B
Dimensions: 16
Weight: 0.05

$6.00

Qty


80008194 / IGEIB4-B
Click for photos
Battery powered push button igniter.
  • Has four (4) spade type male connectors.
  • Uses 1 AAA battery (not supplied)
  • Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IGEIB4-B (Replaces Charbroil 80008194)
Weight: 0.3

$31.52

Qty


TS-IG4010
Click for photos
Push-button electronic igniter with four (4) spade connectors. Black cap. Uses one AAA battery (not included). Requires a 3/4” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: TS-IG4010
Weight: 0.2

$18.49

Qty


04430
Click for photos
Burner mounted electrode for use with 15591 and 15491 burners.
  • 39” wire with female spade connector
  • Includes adapter wire part 03198 for applications needing male spade connector on electrode.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 04430
Material: ceramic
Weight: 0.1

$12.47

Qty


==> All Charbroil Igniter Components.






463260107 Heat indicators and Meat Thermometers

80006666 / 00473
Click for photos
Semi-circular, snap in heat indicator with 2 3/4” heat prob.

Part Number: 00473 (Replaces Charbroil 80006666)
Dimensions: 1 3/4” x 1 3/16”
Material: stainless steel
Weight: 0.1

$14.09

Qty


==> All Charbroil Heat indicators and Meat Thermometers.






463260107 Accessories

BP-6
Wundersmoke Hickory Chips. These unique hickory wood smoking chips add distinctive hickory wood flavoring to your food. For use will all grills. Comes with reusable puck. One 1lb bag.

Part Number: BP-6
Weight: 1.0

$9.75

Qty


SF-1
Click for photos
Stainless steel flipper. The ultimate spatula tool, specially curved for perfect flips every time. 18” overall.

Part Number: SF-1
Dimensions: 18
Material: stainless steel
Weight: 0.4

$15.90

Qty


50426
Click for photos
Aluminum foil grilling trays. Package of three.
  • Heavy duty aluminum foil
  • Re-usable
  • Great for grilling delicate foods like fish and veggies


Part Number: 50426
Dimensions: 9” x 13”
Weight: 0.4

$8.64

Qty


WB-7
Scrub brushes. Plastic grill scrubber. Cleans all types of cooking grids. Plastic grip handle.

Part Number: WB-7
Dimensions: 6” x 3 1/2”
Weight: 0.2

$5.96

Qty


==> All 463260107 Accessories.
