Charbroil Commercial 463241904 Grill Parts

Charbroil 463241904

Char-Broil Commercial Series 4-Burner LP gas grill with side burner

Highest quality replacement parts for your Charbroil Commercial 463241904 - Free USA shipping $49 or more* - No Sales Tax*

Charbroil 463241904 owners manual and diagrams

Diagrams & owners manual not available for grill model# 463241904. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Replacement grill parts to fit Charbroil Commercial 463241904

This page shows all of the parts we know fit model Charbroil 463241904. If the part you're shopping for isn't included below, you might find it using the category buttons on the right side of the page. For example, if your looking for a burner and there are none here, click the burner button to see all the burners we have for Charbroil grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Charbroil 463241904 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Charbroil model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

463241904 Burners

80000431 / CIJA

Click for photos

Cast iron burner for Charbroil model 463241904.

Part Number: CIJA (Replaces Charbroil 80000431)
Dimensions: 15 3/4” x 2 1/4”
Material: cast iron
Weight: 3.4

==> All Charbroil Burners.

463241904 Burner Brackets and Carryovers

80000689 / CLA-MS0302

Click for photos

Stainless steel burner brace with carryover tubes. This part functions as a burner support bracket with integated gas carryover tubes.

All stainless steel construction
Fits 4-burner Terrace and Designer Series grill models
Replaces OEM part numbers 80003053 and 80000689

Made in USA

Part Number: CLA-MS0302 (Replaces Charbroil 80000689)
Dimensions: 1 5/16” x 32 3/16”
Material: Stainless Steel
Weight: 1.3

==> All Charbroil Burner Brackets and Carryovers.

463241904 Cooking Grids

CG-68P-CI-X3

Click for photos

Cast iron cooking grids for Charbroil model 463241904. SET OF THREE (3) panels.

Porcelain treated, matte finish
Each panel measures 18 7/8” x 10 1/2”
Overall dimensions: 18 7/8” x 31 1/2”

Part Number: CG-68P-CI-X3
Dimension Front-to-Back: 18 7/8”
Dimension Side-to-Side: 31 1/2”
Material: cast iron
Weight: 21.6

CG-71P-CI

Click for photos

Cast iron cooking grid for Charbroil model 463241904. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-71P-CI
Dimension Front-to-Back: 18 3/4”
Dimension Side-to-Side: 7 5/8”
Material: cast iron
Weight: 5.55

80000445 / 54453

Click for photos

Porcelain steel cooking grids for Charbroil model 463241904. Porcelain enameled, glossy finish. Sold as a set of three (3). If you prefer a heavier cast iron porcelain enameled glossy finish cooking grid, select four (4) panels of # 65131.

Part Number: 54453 (Replaces Charbroil 80000445)
Dimension Front-to-Back: 18 3/4”
Dimension Side-to-Side: 31 1/2”
Material: porcelain steel wire
Weight: 15.10

CG-68P-CI

Click for photos

Cast iron cooking grid for Charbroil model 463241904. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-68P-CI
Dimension Front-to-Back: 18 7/8”
Dimension Side-to-Side: 10 1/2”
Material: cast iron
Weight: 7.2

==> All Charbroil Cooking Grids.

463241904 Heat Plates

96011

Stainless steel Flame Tamer for Charbroil model 463241904. Sold individually.

Part Number: 96011
Dimension Front-to-Back: 16 1/2”
Dimension Side-to-Side: 5 5/8”
Material: stainless steel
Weight: 1.7

==> All Charbroil Heat Plates.

463241904 Igniter Components

IG-30B

Click for photos

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

IG-48B

Click for photos

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

80000690 / IGEIB4-B

Click for photos

Battery powered push button igniter.

Has four (4) spade type male connectors.
Uses 1 AAA battery (not supplied)
Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IGEIB4-B (Replaces Charbroil 80000690)
Weight: 0.3

TS-IG4010

Click for photos

Push-button electronic igniter with four (4) spade connectors. Black cap. Uses one AAA battery (not included). Requires a 3/4” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: TS-IG4010
Weight: 0.2

==> All Charbroil Igniter Components.

463241904 Knobs and Handles

80000354 / 01700

Click for photos

Black control knob for Fire Magic Custom, Regal, and Gourmet grills.

Off position D-Value: 6 o'clock
Knob diameter: 2”
Socket diameter: 8mm
Knob shaft: None

Part Number: 01700 (Replaces Charbroil 80000354)
Dimensions: 2” x 2”
Material: plastic
Weight: 0.1

01800

Click for photos

Universal black control knob. Counter-clockwise bezel.

Off position D-Value: Selectable
Knob diameter: 2 1/16”
Socket diameter: 8mm
Knob shaft: None

Part Number: 01800
Dimensions: 2 1/16” x 2 1/16”
Material: plastic
Weight: 0.05

==> All Charbroil Knobs and Handles.

463241904 Heat indicators and Meat Thermometers

80000096 / GG-TG4

Click for photos

Round temperature gauge. Fits MHP Grills JNR, WNK, TJK, GJK, WRG, TRG.

2 1/2” diameter.
Single prob
Requires 3/8” mounting hole

Part Number:

GG-TG4

80000096

Weight:

GG-TG3

Click for photos

Rectangular heat indicator for old style MHP grills that has two pegs and a center probe to mount through the casting. It was used on older JNR and WNK grills. We are not sure when MHP changed to the newer heat indicator GG-TG4 that has one larger peg to mount. The GG-TG3 needs two small holes for mounting and one hole in the center for the probe.

Part Number: GG-TG3
Dimensions: 2 5/8” x 2 1/4”
Weight: 0.15

==> All Charbroil Heat indicators and Meat Thermometers.

463241904 Accessories

VTC-B

Click for photos

Venturi Tube 12” Brush. Recommended by all grill manufacturers. Specially designed flexible brush to clean venturis of spider webs and other obstructions that can cause flashback fires. Stainless steel.

Part Number: VTC-B
Material: stainless steel
Weight: 0.3

==> All 463241904 Accessories.
