Charbroil Commercial 463241004 Grill Parts

Charbroil logo



Charbroil 463241004

Char-Broil Commercial Series 4-Burner LP gas grill with side burner



Highest quality replacement parts for your Charbroil Commercial 463241004 - Free USA shipping $49 or more* - No Sales Tax*



Charbroil 463241004 owners manual and diagrams
Diagrams & owners manual not available for grill model# 463241004. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!




Replacement BBQ grill parts for Charbroil Commercial 463241004
On this page you'll find all of the parts that fit model Charbroil 463241004. If you can't find the part you need below, click on the appropriate category button on the right side of the page. For example, if your looking for a cooking grid and there are none here, click the cooking grids button to see all of the cooking grids we have for Charbroil grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Charbroil 463241004 BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Charbroil model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



463241004 Burners

80000431 / CIJA
Click for photos
Cast iron burner for Charbroil model 463241004.


Part Number: CIJA (Replaces Charbroil 80000431)
Dimensions: 15 3/4” x 2 1/4”
Material: cast iron
Weight: 3.4

$34.20
SALE  $28.24
Qty


==> All Charbroil Burners.






463241004 Burner Brackets and Carryovers

80000689 / CLA-MS0302
Click for photos
Stainless steel burner brace with carryover tubes. This part functions as a burner support bracket with integated gas carryover tubes.
  • All stainless steel construction
  • Fits 4-burner Terrace and Designer Series grill models
  • Replaces OEM part numbers 80003053 and 80000689
Made in USA

Part Number: CLA-MS0302 (Replaces Charbroil 80000689)
Dimensions: 1 5/16” x 32 3/16”
Material: Stainless Steel
Weight: 1.3

$35.43

Qty


==> All Charbroil Burner Brackets and Carryovers.






463241004 Cooking Grids

CG-68P-CI
Click for photos
Cast iron cooking grid for Charbroil model 463241004. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-68P-CI
Dimension Front-to-Back: 18 7/8”
Dimension Side-to-Side: 10 1/2”
Material: cast iron
Weight: 7.2

$54.20

Qty


CG-68P-CI-X3
Click for photos
Cast iron cooking grids for Charbroil model 463241004. SET OF THREE (3) panels.
  • Porcelain treated, matte finish
  • Each panel measures 18 7/8” x 10 1/2”
  • Overall dimensions: 18 7/8” x 31 1/2”


Part Number: CG-68P-CI-X3
Dimension Front-to-Back: 18 7/8”
Dimension Side-to-Side: 31 1/2”
Material: cast iron
Weight: 21.6

$140.43

Qty


CG-71P-CI
Click for photos
Cast iron cooking grid for Charbroil model 463241004. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-71P-CI
Dimension Front-to-Back: 18 3/4”
Dimension Side-to-Side: 7 5/8”
Material: cast iron
Weight: 5.55

$43.66

Qty


80000445 / 54453
Click for photos
Porcelain steel cooking grids for Charbroil model 463241004. Porcelain enameled, glossy finish. Sold as a set of three (3). If you prefer a heavier cast iron porcelain enameled glossy finish cooking grid, select four (4) panels of # 65131.

Part Number: 54453 (Replaces Charbroil 80000445)
Dimension Front-to-Back: 18 3/4”
Dimension Side-to-Side: 31 1/2”
Material: porcelain steel wire
Weight: 15.10

$100.62

Qty


==> All Charbroil Cooking Grids.






463241004 Heat Plates

96011
Stainless steel Flame Tamer for Charbroil model 463241004. Sold individually.

Part Number: 96011
Dimension Front-to-Back: 16 1/2”
Dimension Side-to-Side: 5 5/8”
Material: stainless steel
Weight: 1.7

$38.08

Qty


==> All Charbroil Heat Plates.






463241004 Igniter Components

TS-IG4010
Click for photos
Push-button electronic igniter with four (4) spade connectors. Black cap. Uses one AAA battery (not included). Requires a 3/4” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: TS-IG4010
Weight: 0.2

$18.48

Qty


IG-30B
Click for photos
46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-30B
Dimensions: 46
Weight: 0.1

$7.51

Qty


IG-48B
Click for photos
16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-48B
Dimensions: 16
Weight: 0.05

$6.35

Qty


80000690 / IGEIB4-B
Click for photos
Battery powered push button igniter.
  • Has four (4) spade type male connectors.
  • Uses 1 AAA battery (not supplied)
  • Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IGEIB4-B (Replaces Charbroil 80000690)
Weight: 0.3

$34.08

Qty


==> All Charbroil Igniter Components.






463241004 Knobs and Handles

01800
Click for photos
Universal black control knob. Counter-clockwise bezel.
  • Off position D-Value: Selectable
  • Knob diameter: 2 1/16”
  • Socket diameter: 8mm
  • Knob shaft: None


Part Number: 01800
Dimensions: 2 1/16” x 2 1/16”
Material: plastic
Weight: 0.05

$6.55

Qty


80000825 / 01700
Click for photos
Black control knob for Fire Magic Custom, Regal, and Gourmet grills.
  • Off position D-Value: 6 o'clock
  • Knob diameter: 2”
  • Socket diameter: 8mm
  • Knob shaft: None


Part Number: 01700 (Replaces Charbroil 80000825)
Dimensions: 2” x 2”
Material: plastic
Weight: 0.1

$10.84

Qty


==> All Charbroil Knobs and Handles.






463241004 Accessories

BP-7
Wundersmoke Maple Chips. These unique maple wood smoking chips add distinctive maple wood flavoring to your food. For use will all grills. One 1lb bag. Comes with reusable puck.

Part Number: BP-7
Weight: 1.0

$10.42

Qty


SF-1
Click for photos
Stainless steel flipper. The ultimate spatula tool, specially curved for perfect flips every time. 18” overall.

Part Number: SF-1
Dimensions: 18
Material: stainless steel
Weight: 0.4

$15.90

Qty


00030
Click for photos
EZ Check Gas level indicator. Accurate from -22° to 104°F. Magnetic back. Works on all sizes of tanks.

Part Number: 00030
Weight: 0.1

$7.60

Qty


41333
Click for photos
Stainless steel chicken roaster. Commonly called Beer Can roasters.
  • The best way to roast poultry on the grill
  • For use in barbecues and ovens
  • Dishwasher safe
  • Includes rack, rack support, and basting brush


Part Number: 41333
Material: stainless steel
Weight: 0.10

$19.84

Qty


WB-7
Scrub brushes. Plastic grill scrubber. Cleans all types of cooking grids. Plastic grip handle.

Part Number: WB-7
Dimensions: 6” x 3 1/2”
Weight: 0.2

$5.96

Qty


==> All 463241004 Accessories.
