Charbroil Commercial 463240804 Grill Parts

Cast iron burner for Charbroil model 463240804.

Part Number: 24901 (Replaces Charbroil 80000349)
Dimensions: 13 3/4” x 2”
Material: cast iron
Weight: 3.1

Cast iron cooking grids for Charbroil model 463240804. SET OF THREE (3) panels.

• Porcelain treated, matte finish
• Each panel measures 16 7/8” x 8 1/4”
• Overall dimensions: 16 7/8 x 23 3/4”

Part Number: CG-74P-CI-X3
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 24 3/4”
Material: cast iron
Weight: 26.7

Porcelain steel cooking grids for Charbroil model 463240804. Porcelain enameled, glossy finish. Sold as a set of two (2).

Part Number: 52932 (Replaces Charbroil 80000399)
Dimension Front-to-Back: 16 5/8”
Dimension Side-to-Side: 24 1/2”
Material: porcelain steel wire
Weight: 12.11

Heavy duty stainless steel cooking grid for Charbroil model 463240804.

• 304 commercial grade stainless
• Solid 5/16” stainless rods
• Sold individually
• Made in USA.

Part Number: CLA52932S
Dimension Front-to-Back: 16 5/8”
Dimension Side-to-Side: 12 1/4”
Material: solid 304 stainless steel rod
Weight: 6.4

Cast iron cooking grid for Charbroil model 463240804. Porcelain treated, matte finish. Sold individually, number required varies.

Part Number: 66124-1PC
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 8 5/16”
Material: cast iron
Weight: 3.75

Cast iron cooking grid for Charbroil model 463240804. Porcelain treated, matte finish. FIts Kenmore And Other Import Grills. Sold individually, number required varies.

Part Number: CG-74P-CI
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 8 1/4”
Material: cast iron
Weight: 8.90

cast iron cooking grid, SOLD INDIVIDUALLY for Charbroil model 463240804.

• Sold individually.
• Number required varies.
• Porcelain enameled cast iron, flat matte finish.

Part Number: 10225-T536
Dimension Front-to-Back: 17”
Dimension Side-to-Side: 8 1/4”
Material: Cast iron
Weight: 7.6

Cast iron cooking grid for Charbroil model 463240804. Porcelain treated, matte finish. Sold individually, number required varies by grill model.

Part Number: CG-63P-CI (Replaces Charbroil 80000293)
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 11 3/4”
Material: cast iron
Weight: 7.15

Stainless steel heat plate/Flame Tamer for Charbroil model 463240804.


Part Number: CBHP4
Dimension Front-to-Back: 15 1/16”
Dimension Side-to-Side: 4 5/16”
Material: stainless steel
Weight: 0.7

SET OF THREE/3 PACK Stainless steel heat plate/Flame Tamer for Charbroil model 463240804. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0143-X3
Dimension Front-to-Back: 15”
Dimension Side-to-Side: 4 3/16”
Material: stainless steel
Weight: 2.4

Battery powered push button igniter.

• Has four (4) spade type male connectors.
• Uses 1 AAA battery (not supplied)
• Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IGEIB4-B
Weight: 0.3

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

Electrode assembly. Includes electrode with wire, collector box, and mounting bolt with nut. Wire connects to spark generator with flat female spade connector, which is typically used with electronic (battery operated) ignitors (see Ignition 101 in our help center).

Part Number: 00653 (Replaces Charbroil 80000653)
Material: ceramic
Weight: 0.1

Push-button electronic igniter with four (4) spade connectors. Black cap. Uses one AAA battery (not included). Requires a 3/4” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: TS-IG4010
Weight: 0.2

Black control knob for Fire Magic Custom, Regal, and Gourmet grills.

• Off position D-Value: 6 o'clock
• Knob diameter: 2”
• Socket diameter: 8mm
• Knob shaft: None

Part Number: 01700 (Replaces Charbroil 80000035)
Dimensions: 2” x 2”
Material: plastic
Weight: 0.1

Universal black control knob. Counter-clockwise bezel.

• Off position D-Value: Selectable
• Knob diameter: 2 1/16”
• Socket diameter: 8mm
• Knob shaft: None

Part Number: 01800
Dimensions: 2 1/16” x 2 1/16”
Material: plastic
Weight: 0.05

Round heat indicator.

• Single probe
• 1 13/16” diameter
• Requires 3/8” mounting hole

Part Number: 00018
Dimensions: 1 13/16” x 1 13/16”
Weight: 0.1

Round temperature gauge. Fits MHP Grills JNR, WNK, TJK, GJK, WRG, TRG.

• 2 1/2” diameter.
• Single prob
• Requires 3/8” mounting hole

Part Number: GG-TG4 (Replaces Charbroil 80000096)
Weight: 0.15

Rectangular heat indicator for old style MHP grills that has two pegs and a center probe to mount through the casting. It was used on older JNR and WNK grills. We are not sure when MHP changed to the newer heat indicator GG-TG4 that has one larger peg to mount. The GG-TG3 needs two small holes for mounting and one hole in the center for the probe.

Part Number: GG-TG3
Dimensions: 2 5/8” x 2 1/4”
Weight: 0.15

Stainless steel smoker box with cover. For use with all grills. Insert moistened wood chips (not included) for your favorite smoke flavor, 8 3/4” x 3 1/2” x 1 1/2”.


Part Number: SSST
Material: stainless steel
Weight: 1.5

15” Stainless steel tong.

• Soft comfort grip
• Locking mechanism

Part Number: 40259
Dimensions: 15
Material: stainless steel
Weight: 0.14
