Broil-Mate 1159-97 Grill Parts

Genuine OEM Broil-Mate stainless steel burner and venturi assembly for Broil-Mate model 1159-97. Includes burner-mounted igniter electrode and wire part# S15500. Fully assembled.

Part Number: S10017
Dimensions: 8” x 20 1/2”
Material: Stainless steel
Weight: 3.5

Genuine OEM Broil-Mate stainless steel rotisserie burner assembly for Broil-Mate model 1159-97.

Includes:
• 26 3/16” SS rotisserie burner with deflector (part# S13005)
• Burner-mounted electrode, gas collector box, and 45” wire
• Completely assembled

Part Number: S13005A
Dimensions: 26 3/16”
Weight: 1.10

Genuine OEM Broil-Mate cast iron cooking grid, single panel for Broil-Mate model 1159-97.

• Sold individually.
• Number required varies.
• Porcelain treated matte finish.

Part Number: 38170121
Dimension Front-to-Back: 15”
Dimension Side-to-Side: 12 3/4”
Material: Cast Iron
Weight: 5.55

COOKING GRID 390 PORCELAIN, GLOSSY COATED for Broil-Mate model 1159-97. SOLD INDIVIDUALLY.

• Sold individually
• Number required varies, check your grill

Part Number: 04160152
Dimension Front-to-Back: 15 1/16”
Dimension Side-to-Side: 12 13/16”
Material: porcleain steel
Weight: 5.8

10225-E404 Genuine OEM Broil King stainless steel cooking grid for Broil-Mate model 1159-97.

• SOLD INDIVIDUALLY.
• Number required varies, check your grill to be sure.
• Fits Signet and Crown models

Part Number: 10225-E404
Dimension Front-to-Back: 15”
Dimension Side-to-Side: 12 3/4”
Material: Stainless steel
Weight: 5.10

Genuine OEM Broil-Mate reversible heavy cast iron cooking grid SOLD INDIVIDUALLY for Broil-Mate model 1159-97.

• Sold individually
• Number required varies, check your grill
• Porcelain treated, flat matte finish
• Pointed side is designed for perfect sear marks
• Grooved side captures juices for continuous basting

Note: See part 10225-E404 for a stainless steel version of this grid.

Part Number: 10225-T436
Dimension Front-to-Back: 15”
Dimension Side-to-Side: 12 3/4”
Material: Cast iron
Weight: 7.6

Porcelain steel cooking grid for Broil-Mate model 1159-97. Porcelain enameled, glossy finish. Sold individually.

Part Number: 51901
Dimension Front-to-Back: 15 1/16”
Dimension Side-to-Side: 25 1/4”
Material: porcelain steel wire
Weight: 6.13

Genuine OEM Broil-Mate stainless steel Flav-R-Wave heat plate for Broil-Mate model 1159-97. Also replaces porcelain-steel lava rock/briquette grate part# 10222-T424, which has been discontinued by the manufacturer.

Part Number: 10222-T425
Dimension Front-to-Back: 11 1/4”
Dimension Side-to-Side: 23”
Material: Stainless steel
Weight: 3.0

Electronic push-button 1-spade igniter.

• Uses AAA battery (not included)
• Requires 3/4” mounting hole
• Also replaces part 10342-248
• See part number SBB00047 for ignitor that uses a longer lasting AA battery and requires a 7/8” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

This part is currently out of stock, but more are already on the way and expected to arrive late May

Part Number: 10342-244
Weight: 0.3

Genuine OEM Broil-Mate collector box and electrode assembly. Includes

• burner mounted collector box (clip on)
• ceramic electrode and 18” wire with round connector and protective sleeve.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: S15500
Weight: 0.1

Electronic igniter with one (1) spade connector.

• One AA battery required (not included).
• Requires 7/8 inch mounting hole.
• Will have a silver or a black cap.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: SBB00047
Weight: 0.20

Genuine OEM Broil-Mate disposable grease pans. Package of 10. Each measures 4.75”x6”x1”.

Part Number: S15115
Dimensions: 4 3/4” x 6”
Material: aluminum
Weight: 0.25

10472-K431 Control knob large. Black with stainless steel BA strip.

Genuine OEM control knob.

• Off position D-Value: 6 o'clock
• Knob diameter: 2 1/4”
• Socket diameter: 5/16”
• Knob stem: 1/2”

Part Number: 10472-K431
Weight: 0.1

Five piece 3/8” natural gas quick disconnect set includes:

• Part ASCPL-2 12ft vinyl 3/8” ID Sturgis hose (3/8” inside diameter outside diameter about 1/2”) with solid brass fittings
• Part ASCPL-3 Sturgis brand 3/8” quick connect brass coupler
• Hansen & Sturgis dust cover
• plastic dust plug
• Plastic 3/8 MPT Snap Tite
• Suitable up to approximately 60,000 BTU.

Part Number: ASCPL-1
Weight: 3.0

Genuine OEM Broil-Mate 7” cart wheel with 3/8” axel hole. Mini hub cap is # 00400251, sold separately.

Part Number: 10892-7G
Weight: .45

Genuine OEM Broil-Mate caster wheel; approximately 2 3/8” diameter.
This part is currently out of stock, but more are already on the way and expected to arrive late May

Part Number: 10892-15
Weight: 0.35

Genuine OEM Broil-Mate porcelain enameled steel warming rack; also, the same as part number 10225-E391 the chrome version.

Part Number: 10225-E391
Dimensions: 10 1/8” x 23 5/8”
Material: Porcelain steel
Weight: 3.10

Genuine OEM Broil-Mate chrome steel warming rack. Also, the same as part number 10225-E391, the porcelain enameled warming rack.

Part Number: 10225-E390
Dimensions: 10 1/8” x 23 5/8”
Material: Nickel/Chrome
Weight: 3.10

Genuine OEM Broil-Mate Heat indicator. About 2 3/8” wide and 2” high. The threaded stem is about 5 /16” diameter and 1 1/8” long.

Part Number: 10571-6
Weight: 0.12

Hinge pin clip.

Part Number: S21233
Weight: 0.01

ALIGNMENT, BRACKET BLACK

Part Number: 10184-E691
Weight: 1.0

REAR BURNER SPRING

Part Number: S21362
Weight: 1.0

Push nut 3/8

Part Number: S21420
Weight: 0.1

Genuine OEM Broil-Mate End Cap, door. Left hand side, with magnet.
This part is currently out of stock, but more are already on the way and expected to arrive late May

Part Number: 10184-E78A
Dimensions: 9 3/4
Weight: 0.36

END CAP DOOR BOTTOM LEFT A

Part Number: 10184-E76
Dimensions: 10
Weight: .25

Genuine OEM Broil-Mate End Cap, door. RIght hand side, with magnet.

Part Number: 10184-E79A
Weight: 0.36

END CAP DOOR BOTTOM RIGHT A

Part Number: 10184-E77
Dimensions: 10
Weight: .25

Cedar grilling planks adds a delicious wood-smoke flavor to foods grilled on them. Great for salmon! 11 7/8” x 5 1/4” x 5/16” 100% natural cedar. Two planks per pack.

Part Number: 00281
Dimensions: 11 7/8
Weight: .45

Meat Claws.

Shredding pork, chicken, or beef has never been easier. Spare the fork these meat shedding claws can hold with the larger outside tines and shred fine strands of meat with the smaller inside tines. Crafted of stainless steel with an easy to use grip that can be held multiple ways.
Each claw is 8.25 in. in overall length.

Part Number: 44070
Dimensions: 8 1/4
Material: stainless steel
Weight: 0.5

Deluxe non-stick chicken and rib tumble basket. Attaches to rotisserie spit rod.

• Ideal for cooking pieces of meat or vegetables
• Self basting, easy to use
• Locks on spit rod with thumb screw (supplied)
• 6 1/2” x 10” long

Part Number: 24764
Dimensions: 6 1/2” x 10”
Weight: 1.1

Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

Porcelain Coated Round Topper.
11” diameter x 2.5” deep porcelain coated wok with stainless steel handles and perforations. Rolled edge for rigidity and safety.

Part Number: 98130
Dimensions: 11
Material: porcelain steel
Weight: 1.0

Stuffed Burger Press

The stuffed burger press is the best way to make gourmet stuffed and regular burger patties right at home. Easy to disassemble and clean.

Part Number: 24795
Weight: .3
