Grill-Parts home


Broil King Regal XL20 960-27 Grill Parts

Broil King logo



Broil King 960-27



Highest quality replacement parts for your Broil King Regal XL20 960-27 - Free USA shipping $49 or more* - No Sales Tax*



Broil King 960-27 owners manual and diagrams
Click the small images on the right to view Broil King 960-27 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!



Broil King 960-27-303994233-PartsExpS1.jpg  Broil King 960-27-303994233-PartsLstS1.gif  Broil King 960-27-303994233-PartsLstS1.jpg  Broil King 960-27-303994233-PartsLstS2.gif

Replacement BBQ grill parts for Broil King Regal XL20 960-27
All of the parts we have for Broil King 960-27 are shown on this page. We might not show the part you need here but we may still have it, or a functional equivalent. In this case, try the category buttons on the right. For example, if your looking for a heat indicator and there are none here, click the heat indicator button to see all we have for Broil King grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Broil King 960-27 BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Broil King model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



960-27 Burners

10390-T501
Click for photos
Genuine OEM Broil King stainless steel Infinity burner assembly for Broil King model 960-27. This burner assembly does not include the electrodes. Includes:
  • One stainless steel Infinity burner
  • Twin venturi with spider exclusion screens


Part Number: 10390-T501
Dimensions: 8” x 20”
Material: Stainless steel
Weight: 3.2

$74.36

Qty


==> All Broil King Burners.






960-27 Cooking Grids

CG-74P-CI-X3
Click for photos
Cast iron cooking grids for Broil King model 960-27. SET OF THREE (3) panels.
  • Porcelain treated, matte finish
  • Each panel measures 16 7/8” x 8 1/4”
  • Overall dimensions: 16 7/8 x 23 3/4”


Part Number: CG-74P-CI-X3
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 24 3/4”
Material: cast iron
Weight: 26.7

$113.22

Qty


10225-T536
Click for photos
Genuine OEM Broil King cast iron cooking grid, SOLD INDIVIDUALLY for Broil King model 960-27.
  • Sold individually.
  • Number required varies.
  • Porcelain enameled cast iron, flat matte finish.


Part Number: 10225-T536
Dimension Front-to-Back: 17”
Dimension Side-to-Side: 8 1/4”
Material: Cast iron
Weight: 7.6

$56.56

Qty


66124-1PC
Click for photos
Cast iron cooking grid for Broil King model 960-27. Porcelain treated, matte finish. Sold individually, number required varies.

Part Number: 66124-1PC
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 8 5/16”
Material: cast iron
Weight: 3.75

$26.77

Qty


CG-74P-CI
Click for photos
Cast iron cooking grid for Broil King model 960-27. Porcelain treated, matte finish. FIts Kenmore And Other Import Grills. Sold individually, number required varies.

Part Number: CG-74P-CI
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 8 1/4”
Material: cast iron
Weight: 8.90

$43.61

Qty


==> All Broil King Cooking Grids.






960-27 Heat Plates

10222-T425
Click for photos
Genuine OEM Broil King stainless steel Flav-R-Wave heat plate for Broil King model 960-27. Also replaces porcelain-steel part# 10222-T424, which has been discontinued by the manufacturer.

Part Number: 10222-T425
Dimension Front-to-Back: 11 1/4”
Dimension Side-to-Side: 23”
Material: Stainless steel
Weight: 3.0

$48.94

Qty


==> All Broil King Heat Plates.






960-27 Heat Shields

10184-R80
Click for photos
Radiation shield.

Part Number: 10184-R80
Dimensions: 9 1/4” x 20 3/4”
Material: stainless steel
Weight: 1.72

$19.69

Qty


==> All Broil King Heat Shields.






960-27 Igniter Components

10342-245
Click for photos
Genuine OEM Broil King electronic push-button 2-spade igniter.
  • Uses AAA battery (not included)
  • .Requires 3/4” mounting hole
  • Also replaces part# 10342-242 and 10342-249

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 10342-245
Weight: 0.3

$16.46

Qty


10342-T301
Click for photos
Genuine OEM Broil King collector box and electrode assembly. Includes:
  • burner mounted box with mounting screw
  • ceramic electrode and 17” wire with round connector and protective sleeve
  • Use with burners 10390-T401 (14102) and 10390-T501 (14212)

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 10342-T301
Weight: 0.05

$10.95

Qty


==> All Broil King Igniter Components.






960-27 Grease Trays

S15115
Click for photos
Genuine OEM Broil King disposable grease pans. Package of 10. Each measures 4.75”x6”x1”.

Part Number: S15115
Dimensions: 4 3/4” x 6”
Material: aluminum
Weight: 0.25

$15.14

Qty


==> All Broil King Grease Trays.






960-27 Knobs and Handles

10472-K40
Click for photos
Genuine OEM Broil King rotary igniter knob.

Part Number: 10472-K40
Weight: 0.1

$5.15

Qty


10239-7
Click for photos
Triangular handle washer. 1/8 in thick. Made of heat resistant compressed material.

Part Number: 10239-7
Dimensions: 1 1/2” x 1 1/4”
Weight: 0.05

$1.95

Qty


==> All Broil King Knobs and Handles.






960-27 Regulators and Hoses

HR-4B
Click for photos

Type 1 LP Regulator with 22” Pressure Hose and 3/8” Female Flare Fitting.FITS: Up to 60,000 BTUs



Part Number: HR-4B
Dimensions: 22
Weight: 0.8

$34.71

Qty


10111-K45
Click for photos
Genuine OEM Broil King NG gas hose.

Part Number: 10111-K45
Weight: 2.1

$88.71

Qty


==> All Broil King Regulators and Hoses.






960-27 Wheels and Castors

10892-8NG
Click for photos
Genuine OEM Broil King 8” cart wheel with a 3/8” axel hole. Also replaces part# 10892-8, and 10892-8N which have been discontinued. Is a solid rubber wheel with a plastic hub, and it has a grey sidewall stripe instead of the white found on 10892-8N.

Part Number: 10892-8NG
Dimensions: 8
Weight: 1.6

$17.02

Qty


10892-15
Click for photos
Genuine OEM Broil King caster wheel; approximately 2 3/8” diameter.

Part Number: 10892-15
Weight: 0.35

$7.23

Qty


==> All Broil King Wheels and Castors.






960-27 Warming Racks

10225-T528
Click for photos
Genuine OEM Broil King warming rack

Part Number: 10225-T528
Dimensions: 7 3/4” x 24 3/4”
Weight: 4.5

$45.28

Qty


==> All Broil King Warming Racks.






960-27 Heat indicators and Meat Thermometers

10571-6
Click for photos
Genuine OEM Broil King Heat indicator. About 2 3/8” wide and 2” high. The threaded stem is about 5 /16” diameter and 1 1/8” long.

Part Number: 10571-6
Weight: 0.12

$17.77

Qty


==> All Broil King Heat indicators and Meat Thermometers.






960-27 Miscellaneous Repair Parts

S21233
Click for photos
Hinge pin clip.

Part Number: S21233
Weight: 0.01

$1.08

Qty


10184-R19
Click for photos
TANK RETAINER-PEDESTAL-NEW

Part Number: 10184-R19
Weight: 1.0

$4.40

Qty


S21420
Click for photos
Push nut 3/8

Part Number: S21420
Weight: 0.1

$2.23

Qty


Y-6616
Click for photos
Bolt

Part Number: Y-6616
Weight: 0.02

$1.08

Qty


==> All Broil King Miscellaneous Repair Parts.






960-27 Shelves

10184-R581
Click for photos
Shelf support, left.

Part Number: 10184-R581
Weight: 1.5

$10.36

Qty


10711-R562
Click for photos
Genuine OEM Broil King Side shelf, left side.

Part Number: 10711-R562
Weight: 3.10

$51.67

Qty


==> All Broil King Shelves.






960-27 Accessories

WB-1
12” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-1
Dimensions: 12
Weight: 0.4

$10.90

Qty


==> All 960-27 Accessories.
