Broil King Crown 20 944-24 Grill Parts

Genuine OEM Broil King stainless steel burner and venturi assembly for Broil King model 944-24.

Part Number: 10390-T401
Dimensions: 6 1/2” x 14 5/8”
Material: Stainless steel
Weight: 2.3

Genuine OEM Broil King cast iron cooking grid SOLD INDIVIDUALLY for Broil King model 944-24.

• Sold individually
• Number required varies, check your grill
• Porcelain treated, flat matte finish

Part Number: 10225-T356
Dimension Front-to-Back: 14 3/4”
Dimension Side-to-Side: 10 3/4”
Material: Cast iron
Weight: 6.1

Cast iron cooking grids for Broil King model 944-24. Porcelain treated, flat matte finish. Sold as a set of two (2).

Part Number: 63262
Dimension Front-to-Back: 14 3/4”
Dimension Side-to-Side: 21 1/2”
Material: matte cast iron
Weight: 15.1

Genuine OEM Broil King stainless steel Flav-R-Wave SS heat plate for Broil King model 944-24.

Part Number: 10222-T325
Dimension Front-to-Back: 10 3/8”
Dimension Side-to-Side: 18”
Material: Stainless steel
Weight: 2.4

Genuine OEM Broil King electronic push-button 4-spade igniter.

• Uses AAA battery (not included)
• Requires 3/4” mounting hole

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-247
Weight: 0.5

Genuine OEM Broil King collector box and electrode assembly. Includes:

• burner mounted box with mounting screw
• ceramic electrode and 17” wire with round connector and protective sleeve
• Use with burners 10390-T401 (14102) and 10390-T501 (14212)

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-T301
Weight: 0.05

Stainless steel wire grease cup holder for mini bucket #S15112 which has been discontinued and replaced with mini bucket # 4673-FC. This wire holder can also be used with tin cans for easy disposal of grease.

Part Number: S15111
Material: stainless steel
Weight: 0.02

Broil King 64” premium grill cover 67488. Broil King Select Series covers are crafted from durable and weather resistant PVC / 500 x 300 denier polyester lining. These durable covers feature:

• Hook-and-loop tabs that secure the cover around the grill
• Polyester handles for easy removal
• Hanging loops for convenient storage
• The Broil King brand logo on the front

Exact fit for models:

• Baron 540, 590 Series grills
• Crown 20, 40 Series grills, post model
• Signet 20 Series grills
• Sovereign 20, 70, 90 grills

Dimensions:

• Side-to-Side: 64”
• Height: 45.5”
• Front-to-Back: 23”

Part Number: 67488
Weight: 6.0

Broil King 64” premium grill cover 68488. Broil King premium covers are crafted of durable water resistant PVC with heavy woven 900D polyester backing.

Exact fit for Broil King models:

• Baron™ 500 Series
• Signet™ Series ( Prior to 2013 )
• Signet™ 20 ( 2013 to 2015 )
• Sovereign™ 20,70,90 ( Prior to 2013 )
• Crown™ 20, 40 ( After 2012 )

Features:

• Mesh venting for enhanced air flow and moisture resistance
• Hook-and-loop closures for a superior fit
• Blue baseball stitching adds style to the extra-reinforced seams
• Molded rubber handles make the cover easy to remove

Dimensions:

• Side-to-Side: 64”
• Height: 47.5”
• Front-to-Back: 23”

Part Number: 68488
Weight: 6.0

Genuine OEM Broil King rotary igniter knob.

Part Number: 10472-K40
Weight: 0.1

Triangular handle washer. 1/8 in thick. Made of heat resistant compressed material.

Part Number: 10239-7
Dimensions: 1 1/2” x 1 1/4”
Weight: 0.05

Type 1 LP Regulator with 22” Pressure Hose and 3/8” Female Flare Fitting.FITS: Up to 60,000 BTUs

Part Number: HR-4B
Dimensions: 22
Weight: 0.8

Genuine OEM Broil King 7” cart wheel with 3/8” axel hole. Mini hub cap is # 00400251, sold separately.

Part Number: 10892-7G
Weight: .45

Genuine OEM Broil King twin wheel swivel castor, approximately 2 3/8 inch.

Part Number: 10892-13
Weight: 0.35

Wheel bolt 3.25” long; uses one hinge pin part number S21233 not included.

Part Number: 10240-13
Weight: .10

Genuine OEM Broil King LP twin valve assembly. Includes orifices. (CONTROL ASSEMBLY 44M 2V LP T35)

Part Number: 10440-E36
Material: brass/aluminum
Weight: 0.7

Genuine OEM Broil King Heat indicator. About 2 3/8” wide and 2” high. The threaded stem is about 5 /16” diameter and 1 1/8” long.

Part Number: 10571-6
Weight: 0.12

Hinge pin clip.

Part Number: S21233
Weight: 0.01

Bolt

Part Number: Y-6616
Weight: 0.02

Washer

Part Number: S21255
Weight: 0.01

SHELF SUPPORT LH BLK

Part Number: 10184-E461
Weight: 1.0

12” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-1
Dimensions: 12
Weight: 0.4
