Brinkmann Special Edition 810-4400-B Grill Parts

Brinkmann Special Edition 4 Burner Gas Grill

Highest quality replacement parts for your Brinkmann Special Edition 810-4400-B - Free USA shipping $49 or more* - No Sales Tax*

Brinkmann 810-4400-B owners manual and diagrams

Click the small images on the right to view Brinkmann 810-4400-B exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Brinkmann 810-4400-B-31899669996839-PartsExpS1.gif

Replacement grill parts for the Brinkmann Special Edition 810-4400-B

All of the parts we have for Brinkmann 810-4400-B are shown on this page. If you can't find the part you need below, click on the appropriate category button on the right side of the page. For example, if your looking for a heat indicator and there are none here, click the heat indicator button to see all we have for Brinkmann grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Brinkmann 810-4400-B BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Brinkmann model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

810-4400-B Burners

Click for photos

Cast iron burner for Brinkmann model 810-4400-B.

Part Number: CIT-L (Replaces Brinkmann 154-4400-5)
Dimensions: 16 1/4” x 2 3/8”
Material: cast iron
Weight: 4.0

==> All Brinkmann Burners.

810-4400-B Cooking Grids

Click for photos

Cast iron cooking grids for Brinkmann model 810-4400-B. SET OF FOUR (4).

Porcelain treated, matte finish
4 panels, each 17 5/8” x 8 3/4”
Total width: 35”

Part Number: CG-73P-CI-X4 (Replaces Brinkmann 115-4400-0)
Dimension Front-to-Back: 17 5/8”
Dimension Side-to-Side: 35”
Material: cast iron
Weight: 22.20

==> All Brinkmann Cooking Grids.

810-4400-B Heat Plates

Click for photos

Porcelain steel heat tent for Brinkmann model 810-4400-B. Single piece.

Part Number: 90262-1PC (Replaces Brinkmann 600-4402-B)
Dimension Front-to-Back: 15 1/16”
Dimension Side-to-Side: 11 3/4”
Material: porcelain steel
Weight: 3.5

==> All Brinkmann Heat Plates.

810-4400-B Igniter Components

Click for photos

Universal battery powered push button ignitor.

1.5 volt
Has five (5) terminals (male spade connector)
Uses a single AA battery (not included))
03610 and 03620 wires are commonly used with this igniter (not included)
Requires 7/8” mounting hole
Overall dimensions: 2” x 3 3/8” x 3”
Some original igniters had an integrated ground wire. Use wire part# 03620 for this purpose.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 03380
Dimensions: 3 5/16” x 2”
Weight: 0.7

Click for photos

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

Click for photos

Collector box with ceramic igniter electrode and wire.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-21B
Weight: 0.2

==> All Brinkmann Igniter Components.

810-4400-B Knobs and Handles

Click for photos

Black control knob.

Off position D-Value: 12 o'clock
Knob diameter: 2 3/16”
Socket diameter: 8mm (tight fit)
Knob shaft: 3/16”

Part Number: 02500 (Replaces Brinkmann 113-2500-0)
Dimensions: 2 3/16” x 2 3/16”
Material: plastic
Weight: 0.2

==> All Brinkmann Knobs and Handles.

810-4400-B Heat indicators and Meat Thermometers

Click for photos

heat indicator

Part Number: 02351
Dimensions: 2 5/8” x 2 5/8”
Weight: 0.2

==> All Brinkmann Heat indicators and Meat Thermometers.

810-4400-B Accessories

Wundersmoke Hickory Chips. These unique hickory wood smoking chips add distinctive hickory wood flavoring to your food. For use will all grills. Comes with reusable puck. One 1lb bag.

Part Number: BP-6
Weight: 1.0

Click for photos

Stainless steel flipper. The ultimate spatula tool, specially curved for perfect flips every time. 18” overall.

Part Number: SF-1
Dimensions: 18
Material: stainless steel
Weight: 0.4

Click for photos

Aluminum foil grilling trays. Package of three.

Heavy duty aluminum foil
Re-usable
Great for grilling delicate foods like fish and veggies

Part Number: 50426
Dimensions: 9” x 13”
Weight: 0.4

Scrub brushes. Plastic grill scrubber. Cleans all types of cooking grids. Plastic grip handle.

Part Number: WB-7
Dimensions: 6” x 3 1/2”
Weight: 0.2

==> All 810-4400-B Accessories.
