Turbo Grand Turbo YN662AGLP Grill Parts

P02001002E-R1 Cast Iron Burner for Turbo model YN662AGLP.

Fits Grand Turbo models:

• B3807xxx, B3808xxx, B3810xxx, B3812xxx, B3816xxx
• BAI07xxx, BAI08xxx, BAI10xx, BAI12xx, BAI16xxx
• Y0662, Y0663, Y0665
• YN662, YN663, YN662AGLP

Also fits Turbo Select models:

• G5STR, G5STRN
• G6STR, G6STRN.

Also available in more economical 5 and 6 burner multi-packs.

This aftermarket part replaces original Turbo burner part P02001002E.

Part Number: P02001002E-R2 (Replaces Turbo P02001002E)
Dimensions: 16 3/8” x 2 1/8”
Material: cast iron
Weight: 4.0

Cast iron cooking grids for Turbo model YN662AGLP. SET OF THREE (3) panels.

• Porcelain treated, matte finish
• Each panel measures 19 1/4” x 10 3/8”
• Overall dimensions: 19 1/4” x 31 1/8”

Part Number: CG-69P-CI-X3
Dimension Front-to-Back: 19 1/4”
Dimension Side-to-Side: 31 1/8”
Material: cast iron
Weight: 21.3

Premium quality heavy duty stainless steel cooking grid for Turbo model YN662AGLP. Our USA-made premium stainless grids are simply the best obtainable. We have them manufactured here in the USA to our specifications and standards, which are high. Of course, they're not available anywhere else.

Unlike the standard issue stainless grids generally found today, which are typically low grade stainless and sometimes hollow, or coated carbon steel, our premium grids are made from solid high quality stainless steel rods. If you're looking for the best, you've found it. Just look at the weight of one of these grids, over 6 pounds of solid stainless each.

• 304 commercial grade stainless steel
• Large diameter 5/16” solid stainless rods
• Dimensions: 19 1/4” x 10 1/4”
• Made in USA.
• Sold individually.

See part CLA-GS0005-X3 for a more economical 3-pack.

Part Number: CLA-GS0005 (Replaces Turbo P01606002B)
Dimension Front-to-Back: 19 1/4”
Dimension Side-to-Side: 10 1/4”
Material: stainless steel
Weight: 6.3

Cast iron cooking grid for Turbo model YN662AGLP.

• Sold inividually
• Porcelain treated, matte finish
• Number required varies by grill model
• Each panel measures 19 1/4” x 10 3/8”

Part Number: CG-69P-CI
Dimension Front-to-Back: 19 1/4”
Dimension Side-to-Side: 10 3/8”
Material: cast iron
Weight: 7.10

Ceramic Flame Tamer for Grand Turbo for Turbo model YN662AGLP. Measures 7 1/2” x 4 3/4”. Box of 4.

Note: This part is used in racks P01720005B, P01720026B, P0172034B.

Fits models:

YN662LP/NG
• YN662AGLP/NG
• YN663
• And others

Part Number: P01804002A-R (Replaces Turbo P01804002A)
Dimension Front-to-Back: 7 1/16”
Dimension Side-to-Side: 4 3/4”
Material: ceramic
Weight: 4.0

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

Collector box and electrode assembly. fits many kenmore models usinf rail style cast iron burners (Command Flame and Command Flame II systems). The collector box is 4”.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-16B (Replaces Turbo P02610018A)
Dimensions: 4
Weight: 0.2

Battery powered push button igniter.

• Has four (4) spade type male connectors.
• Uses 1 AAA battery (not supplied)
• Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IGEIB4-B (Replaces Turbo P02502024C)
Weight: 0.3

Push-button electronic igniter with four (4) spade connectors. Black cap. Uses one AAA battery (not included). Requires a 3/4” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: TS-IG4010
Weight: 0.2

Straight thru L.P regulator with 28” hose. Adequate to 90,000 BTU.

Part Number: HR-6B (Replaces Turbo P03601011A)
Dimensions: 28
Weight: 1.50

15” Stainless steel tong.

• Soft comfort grip
• Locking mechanism

Part Number: 40259
Dimensions: 15
Material: stainless steel
Weight: 0.14
