Sterling 586164 Grill Parts

Genuine OEM Sterling stainless steel Dual-Tube burner for Sterling model 586164. This part has been slightly changed by the manufacturer to include a small bend at the end that does not affect the fit on existing grills that use this part.

Note: The adjustable air shutter on this burner should be set to 1/3 open for LP grills, 2/3 open for natural gas grills. The burner ships with the air shutter set 1/3 open for LP grills.

This burner is the same part as 22909-104NG and 22909-104LP. There is no difference in the parts, 22909-104NG has the air shutter set to 2/3 open for natural gas, 22909-104LP has the air shutter set to 1/3 open for LP.

Part Number: 22909-104
Dimensions: 17 1/8” x 1 1/4”
Material: Stainless steel
Weight: 1.0

Side burner lid IR stainless steel for Sterling model 586164. Sometimes shipped with vinyl peel-off coating; remove before use.

Part Number: 23000-253
Dimensions: 14 1/4” x 11 3/16”
Material: stainless steel
Weight: 1.6

Cooking grid not known for Sterling model 586164. Our parts information for this grill model is incomplete, and we really don't know with certainty which cooking grid fits this model. It may be that we have the part but don't show it here due to data or other error.

If you know the original OEM part number, try searching for it in the search box at the top of this page.

You can also browse through all of the Sterling cooking grids we carry. If we don't have the exact fit grid for your grill, we may have a suitable replacement part. Measure your existing part as well as the the grid support area of the grill so you'll know exactly what size grids will fit.

If you have this grill model and know the number and dimensions of your original cooking grids, please share this information with us. Click here to send an email to our GrillDr that includes this information. We greatly appreciate your help.

Part Number: CG-DUMMY
Weight: 1.0

Genuine OEM Sterling stainless steel Flav-R-Wave heat plate / Vaporizer for Sterling model 586164. The manufacturer has redesigned this Flav-R-Wave. It is still the functional OEM Sterling replacement part, and it is sometimes marketed as part number 18433.

Part Number: 22209-904
Dimension Front-to-Back: 17 1/2”
Dimension Side-to-Side: 5 7/8”
Material: Stainless steel
Weight: 1.15

Genuine OEM Sterling electronic push-button 3-spade igniter.

• Uses AAA battery (not included)
• .Requires 3/4” mounting hole

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-246
Weight: 0.6

Genuine OEM Sterling rear collector box.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 22205-024
Dimensions: 27 1/8”
Material: stainless steel
Weight: 0.9

Genuine OEM Sterling front collector box, top & bottom combo. Includes top 22215-014 and bottom 22225-014. This part has been redesigned by the manufacturer and is now a little shorter but still fully functional in the original grills. Fits 4-Burner grills.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 22225-014A
Dimensions: 21 5/8
Material: stainless steel
Weight: 1.2

Genuine OEM Sterling electrode and wire for side burner.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-T10
Weight: 0.3

Small grease shield used in-between each burner. Four of these replaces one grease shield # 27245-904. Four of these also replaces one grease shield # 22245-901and five of these replaces one grease shield # 27246-904. Refer to your model number and owner's manual. SOLD INDIVIDUALLY

Part Number: 27249-904
Dimensions: 6 1/2” x 6”
Material: stainless steel
Weight: .35

Genuine OEM Sterling Porcelain Grease Pan.

Part Number: 22009-901
Dimensions: 6 1/2” x 5 1/8”
Weight: .45

LID-HANDLE BENT 500 430 SS. NOTE: The mounting holes, center to center, are 23 1/2” apart.

Part Number: 24005-12A
Dimensions: 25
Weight: .85

Genuine OEM Sterling caster, locking.

Part Number: 10892-25
Weight: 0.85

Genuine OEM Sterling porcelain coated warming rack.

Part Number: 22006-991
Dimensions: 32 5/8” x 8 1/2”
Material: porcelain steel
Weight: 6.0

Genuine OEM Sterling Heat indicator. About 2 3/8” wide and 2” high. The threaded stem is about 5 /16” diameter and 1 1/8” long.

Part Number: 10571-6
Weight: 0.12

Hinge pin clip.

Part Number: S21233
Weight: 0.01

Cotter pin

Part Number: Y-11230
Weight: 0.01

Control panel heat shield. One required per grill.

Part Number: 22005-91
Weight: 1.3

Washer

Part Number: S21255
Weight: 0.01

Genuine OEM Sterling caster bracket

Part Number: 21039-905
Dimensions: 22 5/8” x 4 1/2”
Weight: 2.6

LID BUMPER

Part Number: Y-11231
Weight: 0.01

LOWER BASE SMALL LP 500

Part Number: 21095-445
Weight: 8.8

Stainless steel flipper. The ultimate spatula tool, specially curved for perfect flips every time. 18” overall.

Part Number: SF-1
Dimensions: 18
Material: stainless steel
Weight: 0.4

Scrub brushes. Plastic grill scrubber. Cleans all types of cooking grids. Plastic grip handle.

Part Number: WB-7
Dimensions: 6” x 3 1/2”
Weight: 0.2
