Kenmore 141.157902 Grill Parts

P1935A-R-X4 Cast iron burner set for some Kenmore 4-Burner grills for Kenmore model 141.157902. This aftermarket burner replaces original burner part# P1935A.

This a 4-pack of burners.

Part Number: P1935A-R-X4 (Replaces Kenmore P1935A-X4)
Dimensions: 12 7/8” x 2 1/8”
Material: cast iron
Weight: 8.8

P1935A-R Cast iron burner for some Kenmore 3, 4, and 6 burner grills for Kenmore model 141.157902. This aftermarket burner replaces original burner part# P1935A.

Part Number: P1935A-R (Replaces Kenmore P1935A)
Dimensions: 12 7/8” x 2 1/8”
Material: cast iron
Weight: 2.2

Stainless steel burner support bracket. Replaces OEM # P2218B. Made in USA

Part Number: CLA-MS0293 (Replaces Kenmore P2218B)
Dimensions: 1 3/8” x 23 13/16”
Material: stainless steel
Weight: 0.75

Cast iron cooking grids for Kenmore model 141.157902. SET OF TWO (2) panels.

• Porcelain treated, matte finish
• Each panel measures 16 1/2” x 11 3/8”
• Overall dimensions: 16 1/2” x 22 3/4”

Part Number: CG-92P-CI-X2 (Replaces Kenmore P1648B)
Dimension Front-to-Back: 16 1/2”
Dimension Side-to-Side: 22/4”
Material: cast iron
Weight: 20

Cooking Grid 304 Grade Stainless Steel for Kenmore model 141.157902.225” Rods.

Part Number: CG-51SS
Dimension Front-to-Back: 16 1/2”
Dimension Side-to-Side: 11 1/4”
Material: stainless steel
Weight: 3.50

Cast Iron cooking grid for Kenmore model 141.157902.

Part Number: CG-92P-CI
Dimension Front-to-Back: 16 1/2”
Dimension Side-to-Side: 11 3/8”
Material: cast iron
Weight: 10

Premium quality stainless steel cooking grids for Kenmore model 141.157902. SET OF TWO (2). Far superior to the porcelain coated steel grids it replaces.

• Made in USA
• 304 commercial grade stainless steel
• .225 diameter solid stainless rods

• Each panel measures 16 1/2” x 11 1/4”
• Overall dimensions: 16 1/2” x 22 1/2”

.

Part Number: CG-51SS-X2
Dimension Front-to-Back: 16 1/2”
Dimension Side-to-Side: 22 1/2”
Material: stainless steel
Weight: 7.0

Stainless steel heat plate/ Flame Tamer for Kenmore model 141.157902.

Part Number: KENHP1 (Replaces Kenmore P1733A)
Dimension Front-to-Back: 13 1/8”
Dimension Side-to-Side: 10 9/16”
Material: stainless steel
Weight: 1.0

SET OF THREE/3 PACK Stainless steel heat plate/Flame Tamer for Kenmore model 141.157902. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0154-X3
Dimension Front-to-Back: 13 3/16”
Dimension Side-to-Side: 10 5/8”
Material: stainless steel
Weight: 5.76

Stainless steel heat plate/Flame Tamer for Kenmore model 141.157902. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0154
Dimension Front-to-Back: 13 3/16”
Dimension Side-to-Side: 10 5/8”
Material: stainless steel
Weight: 1.92

Porcelain steel Flame Tamer for Kenmore model 141.157902. Sold individually.


Part Number: 97061
Dimension Front-to-Back: 13 1/8”
Dimension Side-to-Side: 10 9/16”
Material: porcelain steel
Weight: 4.9

Collector box and electrode assembly. fits many kenmore models usinf rail style cast iron burners (Command Flame and Command Flame II systems). The collector box is 4”.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-16B (Replaces Kenmore P02605013C)
Dimensions: 4
Weight: 0.2

Battery powered push button igniter.

• Has two (2) spade type male connectors.
• Uses 1 AAA battery (not supplied)
• Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IGEIB2-B (Replaces Kenmore P02502252C)
Weight: 0.3

Push-button electronic igniter with two (2) spade connectors. Black cap. 1 AAA battery (not included).

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: TS-IG2006
Weight: 0.2

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

Black control knob to fit Kenmore models.

Part Number: 03430 (Replaces Kenmore P3409B)
Dimensions: 2 3/16” x 2 3/16”
Material: plastic
Weight: 0.2

Clamp-on brass gas valve with straight outlet. Includes orifice.

• D-Value: 12 o'clock
• Stem diameter: 6mm
• Stem length: 1 3/4”

Includes orifice with #72 starter hole. Must be drilled to proper drill size.

Part Number: 3700C (Replaces Kenmore P3297C)
Dimensions: 4 15/16” x 2 1/8”
Material: brass
Weight: 0.5

Neoprene valve gasket for clamp-on gas control valves. 19mm.

Part Number: 00019
Dimensions: 0 1/2” x 0 1/4”
Material: neoprene
Weight: 0.01

Brass orifice. 6mm x 3/4” cone shaped orifice with #64 drill size starter hole. For Electec and other clamp-on valves. Must be drilled to proper drill size.

If you would like us to drill the orifice(s) for you, there is a single $15 fee for this service, which will be added to the order when processed. Please tell us the number of burners in your grill and the total BTUs of your grill (less side burner and rotisserie burner, if any). BTU rating information can usually be found on the grill's CSA certification tag, located somewhere on the grill. Please furnish this, along with any other information you deem relevant, in the Message to CLA box during checkout.

Part Number: 31400
Dimensions: 0 3/4” x 0 5/16”
Material: brass
Weight: 0.01

Cedar grilling planks adds a delicious wood-smoke flavor to foods grilled on them. Great for salmon! 11 7/8” x 5 1/4” x 5/16” 100% natural cedar. Two planks per pack.

Part Number: 00281
Dimensions: 11 7/8
Weight: .45

5-piece unique tennis oriented utensil set. Constructed of heavy stainless steel with ”tennis grips” on each utensil. Includes yellow tennis ball style salt & pepper shakers, along with spatula, fork and tong.

Makes a nice gift.for tennis-minded folks

Part Number: US10
Weight: 5.00

Deluxe non-stick chicken and rib tumble basket. Attaches to rotisserie spit rod.

• Ideal for cooking pieces of meat or vegetables
• Self basting, easy to use
• Locks on spit rod with thumb screw (supplied)
• 6 1/2” x 10” long

Part Number: 24764
Dimensions: 6 1/2” x 10”
Weight: 1.1

Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

Roast holder. This holder is an ideal way to cook and also carry a roast from the grill. Made of heavy, bright nickel-plated steel, 15 1/4” L x 10 1/2” W.

Part Number: RR-3
Dimensions: 19 1/2
Weight: 1.0

Stainless Steel Scraper for Phoenix and Holland Drip Trays

Part Number: SDDPS
Dimensions: 20
Weight: 0.30
