Glen Canyon 720-0152-LP Grill Parts

304 Stainless steel Infrared rear rotisserie burner with ceramic wafer for Glen Canyon model 720-0152-LP. For use with both liquid propane (LP) and natural gas grills. 8,000 BTU. Orifice not included. Use old orifice or purchase our orifice part# CLA-VB0245 for LP, or part# CLA-VB0246 for natural gas applications.

Dimensions:

• Maximum overall length, including mounting tab on one end: 17”
• Maximum width: 3 3/8”
• Burner box 15 3/8” x 3 3/8”
• Mounting holes: 16 1/8” on center

Part Number: CLA-BL0229
Dimensions: 3 3/8” x 17”
Material: stainless steel and ceramic
Weight: 3.0

Cast iron burner for Glen Canyon model 720-0152-LP.

Part Number: CIT
Dimensions: 15 3/4” x 2 7/8”
Material: cast iron
Weight: 4.2

Cast stainless steel burner for Glen Canyon model 720-0152-LP. Tired of changing out rusted cast iron burners? Far superior to the cast iron and brass versions, this burner will probably outlast your grill. Designed to replace cast iron and brass burners of same design.

NOTE: This burner is equiped with an air intake adjustable control shutter (not shown in photos) and with an air intake control screw for regulating the air/gas mixture into the burner. Natural gas applications require more air (more open screw) than lquid propane (LP). If necessary, adjust screw to get a yellow-tipped blue flame.

Part Number: 23301-CSS
Dimensions: 16” x 2 7/16”
Material: cast stainless steel
Weight: 3.2

Premium quality heavy duty stainless steel cooking grid for Glen Canyon model 720-0152-LP. Our USA-made premium stainless grids are simply the best obtainable. We have them manufactured here in the USA to our specifications and standards, which are high. Of course, they're not available anywhere else.

Unlike the standard issue stainless grids generally found today, which are typically low grade stainless and sometimes hollow, or coated carbon steel, our premium grids are made from solid high quality stainless steel rods. If you're looking for the best, you've found it. Just look at the weight of one of these grids, over 6 pounds of solid stainless each.

• 304 commercial grade stainless steel
• Large diameter 5/16” solid stainless rods
• Dimensions: 19 1/4” x 10 1/4”
• Made in USA.
• Sold individually.

See part CLA-GS0005-X3 for a more economical 3-pack.

Part Number: CLA-GS0005
Dimension Front-to-Back: 19 1/4”
Dimension Side-to-Side: 10 1/4”
Material: stainless steel
Weight: 6.3

Cast iron cooking grids for Glen Canyon model 720-0152-LP. SET OF THREE (3) panels.

• Porcelain treated, matte finish
• Each panel measures 19 1/4” x 10 3/8”
• Overall dimensions: 19 1/4” x 31 1/8”

Part Number: CG-69P-CI-X3
Dimension Front-to-Back: 19 1/4”
Dimension Side-to-Side: 31 1/8”
Material: cast iron
Weight: 21.3

Premium quality stainless steel cooking grid for Glen Canyon model 720-0152-LP. Our USA-made premium stainless grids are simply the best obtainable. We have them manufactured here in the USA to our specifications and standards, which are high. Of course, they're not available anywhere else.

Unlike the standard issue stainless grids generally found today, which are typically low grade stainless and sometimes hollow, or coated carbon steel, our premium grids are made from solid high quality stainless steel rods. If you're looking for the best, you've found it.

• 304 commercial grade stainless steel
• 1/4” diameter solid stainless rods
• Dimensions: 18 7/8” x 10”
• Made in USA.
• Sold individually.

Part Number: CLS9151
Dimension Front-to-Back: 18 7/8”
Dimension Side-to-Side: 10”
Material: solid stainless steel
Weight: 4.0

Cast iron cooking grid for Glen Canyon model 720-0152-LP.

• Sold inividually
• Porcelain treated, matte finish
• Number required varies by grill model
• Each panel measures 19 1/4” x 10 3/8”

Part Number: CG-69P-CI
Dimension Front-to-Back: 19 1/4”
Dimension Side-to-Side: 10 3/8”
Material: cast iron
Weight: 7.10

Stainless steel Flame Tamer for Glen Canyon model 720-0152-LP.

Part Number: NGCHP2
Dimension Front-to-Back: 17 3/4”
Dimension Side-to-Side: 6 3/8”
Material: stainless steel
Weight: 0.7

SET OF THREE/3 PACK Stainless steel Flame Tamer/heat plate for Glen Canyon model 720-0152-LP.

This heat plate also provides an economical alternative to some other heat plates with the same front-to-back dimension.

• Sold individually, number required varies.
• Shipped with protective peel-off coating, remove before use.
• Made in USA.

Part Number: CLA-TS0020-X3
Dimension Front-to-Back: 17 3/4”
Dimension Side-to-Side: 6 3/8”
Material: stainless steel
Weight: 2.4

SET OF FOUR/4 PACK Stainless steel Flame Tamer/heat plate for Glen Canyon model 720-0152-LP.

This heat plate also provides an economical alternative to some other heat plates with the same front-to-back dimension.

• Sold individually, number required varies.
• Shipped with protective peel-off coating, remove before use.
• Made in USA.

Part Number: CLA-TS0020-X4
Dimension Front-to-Back: 17 3/4”
Dimension Side-to-Side: 6 3/8”
Material: stainless steel
Weight: 3.2

control knob..

• Off position D-Value: 6 or 12 o'clock
• Knob diameter: 2 1/4”
• Socket diameter: 8mm
• Knob shaft: none (flat)

Part Number: 472-C565
Weight: 0.1

#63 orifice for infrared burner CLA-BL0229; use on liquid propane (LP) gas grills. Includes brass elbow with 1/4” compression fitting.

Part Number: CLA-VB0245
Dimensions: 3 3/8” x 17 1/4”
Material: stainless steel and ceramic
Weight: 0.3

#55 orifice for infrared burners use on natural Gas grills. Includes brass elbow with 1/4” compression fitting.

Part Number: CLA-VB0246
Dimensions: 3 3/8” x 17 1/4”
Material: stainless steel and ceramic
Weight: 0.3

Stainless steel straight handle grill brush with replaceable head. Brass bristles and scarper. See part# WB-8RH for replacement grill brush heads. 18 1/2” long.
This part is currently out of stock, but more are already on the way and expected to arrive SPRING 23

Part Number: WB-8
Dimensions: 18 1/2
Material: stainless steel
Weight: 0.8
