Fiesta Optima ESD45055-BC347 Grill Parts

Stainless steel burner and venturi assembly kit for Fiesta model ESD45055-BC347. Comes with all necessary gaskets and screws.

Part Number: 19202-79402
Dimensions: 22” x 7 7/8”
Material: stainless steel
Weight: 3.5

Stainless steel H burner for Fiesta model ESD45055-BC347. Burner consists of two pieces, which are held together by the venturi.

Part Number: 19202
Dimensions: 22” x 7 7/8”
Material: stainless steel
Weight: 2.4

Universal Spider Guards. Helps prevent dangerous flashback fires caused by spider webs in venturi tubes.Stainless steel spider guards slip over the air shutter on most venturi tubes to help keep the spiders out. For 3/4” venturi tubes.

Part Number: SG-B
Material: stainless steel
Weight: 0.1

L-shaped venturi pair. Includes all necessary gaskets and screws/nuts.

Part Number: 79402
Dimensions: 5 1/2” x 3 1/8”
Material: zinc plated steel
Weight: 0.9

Porcelain steel cooking grid for Fiesta model ESD45055-BC347. Porcelain enameled, glossy finish. Sold individually.

Part Number: 58211 (Replaces Fiesta SP102A-3)
Dimension Front-to-Back: 15”
Dimension Side-to-Side: 26 9/16”
Material: porcelain steel wire
Weight: 4.12

Rock grate for holding lava rock or ceramic briquettes.

Part Number: BG-2
Dimension Front-to-Back: 12”
Dimension Side-to-Side: 22 3/4”
Material: carbon steel
Weight: 3.9

Stainless steel version replacement for original Smart Bar SP25-9G for Fiesta model ESD45055-BC347. NOTE: The original part was porcelain coated steel. Far superior to the original, this aftermarket part is made of corrosion-resistant stainless steel for longer life.

Part Number: SP25-9G-SS
Dimension Front-to-Back: 10 1/2”
Dimension Side-to-Side: 23 3/4”
Material: stainless steel
Weight: 3.0

SET OF THREE/3 PACK Stainless steel heat plate/Flame Tamer for Fiesta model ESD45055-BC347. Made in USA.

NOTE: Sometimes shipped with vinyl peel-off coating. Remove before use.

Part Number: CLA-TS0234-X3
Dimension Front-to-Back: 16 15/16”
Dimension Side-to-Side: 5 1/8”
Material: stainless steel
Weight: 3.0

Universal extention wire, male spade end & female round end.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-46B
Dimensions: 2 1/2
Weight: 0.10

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

Electrode kit.

• Mounting bracket
• Electrode with ceramic insulator
• Wire with round connector
• Protective sleeve

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 04300
Material: ceramic
Weight: 0.1

Universal collector box with electrode and wire. Fits most H burners, cast iron and stainless. Mounts to burner using venturi screws. Slotted construction allow universal adjustment of electrode position.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-15B
Weight: 0.3

Battery powered push button igniter.

• Has four (4) spade type male connectors.
• Uses 1 AAA battery (not supplied)
• Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IGEIB4-B (Replaces Fiesta SP5010-20)
Weight: 0.3

ELECTRODE CLIP-ON

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: SP9A-20
Weight: 0.4

Push-button electronic igniter with four (4) spade connectors. Black cap. Uses one AAA battery (not included). Requires a 3/4” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: TS-IG4010
Weight: 0.2

HANDLE 450 D LID COPPER

Part Number: SM5050-42C
Weight: 1.0

KNOB DELUXE

Part Number: SP10-7
Weight: 1.0

Side burner knob.

• Off position D-Value: 6 o'clock
• Knob diameter: 2 3/16”
• Socket diameter: 5/16”
• Knob shaft: 1/8”

Part Number: SP9-7
Weight: 0.1

Universal warming rack. For use on grills with at least 22” inside dimension.

Part Number: AP-6A
Dimensions: 6” x 21 1/2”
Material: Chrome steel
Weight: 1.3

VHR ASSEMBLY 40058

Part Number: SP150A-4
Weight: 1.0

SMART ROD 345/400/450

Part Number: SM68-6
Dimensions: 12
Weight: 0.3

Durable 2 5/16” round briquettes

• Self-cleaning
• Control flare-ups while holding an even heat pattern.
• About 53 pieces, covers approximately 275 sq. inches.
• Fits all gas grills

Part Number: BQ-5
Weight: 7.2

Natural lava rock processed and screened for uniformity. 7 lb. bag is enough for all full sized grills. Click the photo to find easy steps for installing lava rocks.

Part Number: 45887
Material: pummise
Weight: 7.0

Wundersmoke Mesquite Chips. These unique mesquite wood smoking chips add distinctive flavoring to your food. For use will all grills. Comes with reusable puck. One 1lb bag.

Part Number: BP-5
Weight: 1.0

Fish Spatula. Stainless steel fish spatula with genuine rosewood handle. 18 1/2”. 10” spatula width.

Part Number: FS-1
Dimensions: 18 1/2
Material: stainless steel
Weight: 1.0

18” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-3
Dimensions: 18
Weight: 0.59
