Dynasty DOBQ4200B Grill Parts

Highest quality replacement parts for your Dynasty DOBQ4200B - Free USA shipping $49 or more* - No Sales Tax*

Dynasty DOBQ4200B owners manual and diagrams

Diagrams & owners manual not available for grill model# DOBQ4200B. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Replacement grill parts for Dynasty model: DOBQ4200B

On this page you'll find all of the parts that fit model Dynasty DOBQ4200B. We might not show the part you need here but we may still have it, or a functional equivalent. In this case, try the category buttons on the right. For example, if your looking for a cooking grid and there are none here, click the cooking grids button to see all of the cooking grids we have for Dynasty grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Dynasty DOBQ4200B BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Dynasty model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

DOBQ4200B Burners

Click for photos

Cast iron burner and venturi assembly for Dynasty model DOBQ4200B.

Part Number: CIDYN (Replaces Dynasty 70002056)
Dimensions: 18” x 7 3/4”
Material: cast iron
Weight: 10.0

==> All Dynasty Burners.

DOBQ4200B Cooking Grids

Click for photos

Heavy duty cooking grid with 3/8” diameter solid stainless rods for Dynasty model DOBQ4200B.

Part Number: CG-93SS (Replaces Dynasty 70001724)
Dimension Front-to-Back: 19 7/8”
Dimension Side-to-Side: 8 1/2”
Weight: 7.0

==> All Dynasty Cooking Grids.

DOBQ4200B Radiant Trays

Click for photos

Stainless Steel Heat Plate without notched corner for Many Dynasty Grills. Sold individually. Briquettes not included, see part numbers BQLYX and 41650.

Part Number: DYNHP1 (Replaces Dynasty 70002637)
Dimensions: 18” x 11 1/4”
Material: stainless steel
Weight: 1.0

==> All Dynasty Radiant Trays.

DOBQ4200B Igniter Components

Click for photos

Universal collector box with electrode and wire. Fits most H burners, cast iron and stainless. Mounts to burner using venturi screws. Slotted construction allow universal adjustment of electrode position.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-15B
Weight: 0.3

==> All Dynasty Igniter Components.

DOBQ4200B Accessories

Click for photos

Ceramic briquettes for Lynx and Dynasty Grills with 28 briquettes per box.

Part Number: BQLYX
Dimensions: 2” x 2”
Material: ceramic
Weight: 4.0

Ceramic briquettes 48 pieces. Fits briquette trays 94751, 92571 and and simular trays. Works in all grills designed for briquettes or lava rock. Each briquette measures 2” x 2” x 3/4".

Part Number: 41648
Dimensions: 2” x 2”
Material: ceramic
Weight: 7.5

Click for photos

Stainless steel smoker box with cover. For use with all grills. Insert moistened wood chips (not included) for your favorite smoke flavor, 8 3/4” x 3 1/2” x 1 1/2”.

Part Number: SSST
Material: stainless steel
Weight: 1.5

12” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-1
Dimensions: 12
Weight: 0.4

==> All DOBQ4200B Accessories.
