Cook-On SKU-168039 Grill Parts

Cast stainless steel burner for Cook-On model SKU-168039. Tired of changing out rusted cast iron burners? Far superior to the cast iron and brass versions, this burner will probably outlast your grill. Designed to replace cast iron and brass burners of same design.

NOTE: This burner is equiped with an air intake adjustable control shutter (not shown in photos) and with an air intake control screw for regulating the air/gas mixture into the burner. Natural gas applications require more air (more open screw) than lquid propane (LP). If necessary, adjust screw to get a yellow-tipped blue flame.

Part Number: 23301-CSS
Dimensions: 16” x 2 7/16”
Material: cast stainless steel
Weight: 3.2

Cast iron burner for Cook-On model SKU-168039.

Part Number: CIT
Dimensions: 15 3/4” x 2 7/8”
Material: cast iron
Weight: 4.2

Premium quality heavy duty stainless steel cooking grid for Cook-On model SKU-168039. Our USA-made premium stainless grids are simply the best obtainable. We have them manufactured here in the USA to our specifications and standards, which are high. Of course, they're not available anywhere else.

Unlike the standard issue stainless grids generally found today, which are typically low grade stainless and sometimes hollow, or coated carbon steel, our premium grids are made from solid high quality stainless steel rods. If you're looking for the best, you've found it. Just look at the weight of one of these grids, over 6 pounds of solid stainless each.

• 304 commercial grade stainless steel
• Large diameter 5/16” solid stainless rods
• Dimensions: 19 1/4” x 10 1/4”
• Made in USA.
• Sold individually.

See part CLA-GS0005-X3 for a more economical 3-pack.

Part Number: CLA-GS0005
Dimension Front-to-Back: 19 1/4”
Dimension Side-to-Side: 10 1/4”
Material: stainless steel
Weight: 6.3

Cast iron cooking grid for Cook-On model SKU-168039.

• Sold inividually
• Porcelain treated, matte finish
• Number required varies by grill model
• Each panel measures 19 1/4” x 10 3/8”

Part Number: CG-69P-CI
Dimension Front-to-Back: 19 1/4”
Dimension Side-to-Side: 10 3/8”
Material: cast iron
Weight: 7.10

Cast iron cooking grids for Cook-On model SKU-168039. SET OF THREE (3) panels.

• Porcelain treated, matte finish
• Each panel measures 19 1/4” x 10 3/8”
• Overall dimensions: 19 1/4” x 31 1/8”

Part Number: CG-69P-CI-X3
Dimension Front-to-Back: 19 1/4”
Dimension Side-to-Side: 31 1/8”
Material: cast iron
Weight: 21.3

Cast iron cooking grids for Cook-On model SKU-168039. SET OF TWO (2) panels.

• Porcelain treated, matte finish
• Each panel measures 19 1/8” x 7 5/8”
• Total width: 15 1/4”

Part Number: CG-60P-CI-X2
Dimension Front-to-Back: 19 1/8”
Dimension Side-to-Side: 15 1/4”
Material: cast iron
Weight: 11.3

Cast iron cooking grid for Cook-On model SKU-168039. Porcelain treated, matte finish. Sold individually, number required varies by grill model

Part Number: CG-60P-CI
Dimension Front-to-Back: 19 1/8”
Dimension Side-to-Side: 7 5/8”
Material: cast iron
Weight: 5.65

Stainless steel Flame Tamer with 17 ceramic briquettes. This part also replaces an older 16-briquette version that was a little shorter and a bit narrower.

Part Number: TCCFT
Dimension Front-to-Back: 18 1/8”
Dimension Side-to-Side: 7 1/4”
Material: stainless steel
Weight: 5.0

Stainless steel Heat Tent for Cook-On model SKU-168039.

Part Number: COHP1
Dimension Front-to-Back: 16 1/2”
Dimension Side-to-Side: 6 1/4”
Material: stainless steel
Weight: 1.45

Push-button electronic igniter with four (4) spade connectors. Black cap. Uses one AAA battery (not included). Requires a 3/4” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: TS-IG4010
Weight: 0.2

Battery powered push button igniter.

• Has four (4) spade type male connectors.
• Uses 1 AAA battery (not supplied)
• Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IGEIB4-B
Weight: 0.3

46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-30B
Dimensions: 46
Weight: 0.1

16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-48B
Dimensions: 16
Weight: 0.05

Heavy duty stainless steel 6 1/4” x 4” x 2 1/8” cased universal rotisserie motor. On-off switch and 3 foot cord. Maximum 25 lb. balanced load. (120V, 9W, 50/60 HZ, RPM: 2.5/2.8)

Part Number: RO-6
Material: Stainless steel case
Weight: 2.0

Ceramic briquette. Briquettes collect heat and radiate it to the food on the cooking grids. They also help prevent flare-ups and keep the flames from actually touching the food allowing for more efficient and uniform heat distribution.

Designed primarily to work in stainless steel trays on Lynx, Alfresco, and other brand grills, these briquettes can be and often are used on any grill with an ordinary grate to support them.

• Individual briquettes measure 2” x 2”
• Set includes 28 ceramic briquettes
• More than one set may be required per grill model

Part Number: BQLYX
Dimensions: 2” x 2”
Material: ceramic
Weight: 4.0

Ceramic briquettes 48 pieces. Fits briquette trays 94751, 92571 and and simular trays. Works in all grills designed for briquettes or lava rock. Each briquette measures 2” x 2” x 3/4".

Part Number: 41648
Dimensions: 2” x 2”
Material: ceramic
Weight: 7.5

50-piece ceramic briquette set. Works in all grills designed for briquettes or lava rock. Fits briquette tray parts 94751, 92571 and other simular trays.

Part Number: 41650
Dimensions: 2” x 2”
Material: ceramic
Weight: 7.2

Wundersmoke Hickory Chips. These unique hickory wood smoking chips add distinctive hickory wood flavoring to your food. For use will all grills. Comes with reusable puck. One 1lb bag.

Part Number: BP-6
Weight: 1.0

Extra long stainless steel fork with ergonomically correct handles. 20 1/2” long.

Part Number: ITF-2
Dimensions: 20 1/2
Material: stainless steel
Weight: 0.3

Universal 6 piece chrome plated skewer set. Designed so food does not rotate. Great for kabobs! 19 1/2” long.

Part Number: SR-7B
Dimensions: 19 1/2
Material: chrome steel
Weight: 1.0

Marinade Injector.

For injecting flavor and marinades into meat. Disassembles for cleaning. Stainless steel injector tip. Graduated injection chamber.

Part Number: 14950
Material: stailess steel
Weight: 0.5

12” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-1
Dimensions: 12
Weight: 0.4
