Coleman Even Heat G53104 Grill Parts

Coleman logo



Coleman G53104

Coleman EVEN HEAT™ Dual Fuel Charcoal/Natural Gas Barbecue



Highest quality replacement parts for your Coleman Even Heat G53104 - Free USA shipping $49 or more* - No Sales Tax*



Coleman G53104 owners manual and diagrams
Click the small images on the right to view Coleman G53104 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!



Coleman G53104-4E4589633-PartsExpS1.jpg  Coleman G53104-4E4589633-PartsLstS1.gif

Replacement grill parts for the Coleman Even Heat G53104
This page shows all of the parts we know fit model Coleman G53104. If you can't find the part you need below, click on the appropriate category button on the right side of the page. For example, if your looking for an ignitor, or other ignition components, and there are none here, click the ignition button to see what we have for Coleman grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Coleman G53104 BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Coleman model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



G53104 Cooking Grids

65253
Click for photos
Cast iron cooking grids for Coleman model G53104. Porcelain treated, flat matte finish. Sold as a set of three (3).

Part Number: 65253
Dimension Front-to-Back: 18 3/8”
Dimension Side-to-Side: 26 7/16”
Material: matte cast iron
Weight: 16.5

$98.96

Qty


==> All Coleman Cooking Grids.






G53104 Heat Plates

93331
Click for photos
Porcelain steel Heat Distribution Plate for Coleman model G53104. Sold individually.

Part Number: 93331
Dimension Front-to-Back: 16”
Dimension Side-to-Side: 5 13/16”
Material: porcelain steel
Weight: 1.4

$23.33

Qty


==> All Coleman Heat Plates.






G53104 Igniter Components

03152
Click for photos
Ignition module switch for spark generators that accept wired remote (button) trigger switches. Fits our spark generator part numbers 03322, 03332, 03344, 03352, 03356, 03387 and 03388.
Includes:
  • Push-button ignition module switch with two male spade connectors on back
  • Two 20” wires with female spade connectors
  • One plastic mounting nut

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 03152
Dimensions: 17 3/4” x 1”
Weight: 0.1

$19.80

Qty


03153
Click for photos
round trigger switch for AA and AAA spark generators; use original wires

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 03153
Dimensions: 17 3/4” x 1”
Weight: 0.1

$18.33

Qty


03332
Click for photos
Battery powered ignitor/spark generator for Surefire electronic ignition systems using remote button/trigger.
  • 1.5 volt
  • Has three (3) spark outlets (male spade connector)
  • Has two (2) male spade connectors for trigger (button) part #03152 (sold separately)
  • Uses a single AA battery (not included)
  • Requires 7/8” mounting hole
NOTE: The battery cap is not a push button. The ignitor is fired by a remote button/switch.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 03332
Dimensions: 2 5/8” x 2 5/8”
Weight: 0.3

$35.57

Qty


05223
Click for photos
electrode

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: 05223
Material: ceramic
Weight: 0.1

$9.42

Qty


==> All Coleman Igniter Components.






G53104 Heat indicators and Meat Thermometers

00012
Click for photos
Round 2 3/8” diameter heat indicator, includes one wing nut and one locking nut.
  • Requires minimum 3/8” mounting hole
  • Single 1 3/8” probe
  • Threaded portion of probe stops at 1/2” from base
  • See photo for details


Part Number: 00012
Dimensions: 2 3/8” x 2 3/8”
Weight: 0.1

$15.16

Qty


==> All Coleman Heat indicators and Meat Thermometers.






G53104 Accessories

BP-7
Wundersmoke Maple Chips. These unique maple wood smoking chips add distinctive maple wood flavoring to your food. For use will all grills. One 1lb bag. Comes with reusable puck.

Part Number: BP-7
Weight: 1.0

$9.75

Qty


SF-1
Click for photos
Stainless steel flipper. The ultimate spatula tool, specially curved for perfect flips every time. 18” overall.

Part Number: SF-1
Dimensions: 18
Material: stainless steel
Weight: 0.4

$15.90

Qty


00030
Click for photos
EZ Check Gas level indicator. Accurate from -22° to 104°F. Magnetic back. Works on all sizes of tanks.

Part Number: 00030
Weight: 0.1

$7.60

Qty


41333
Click for photos
Stainless steel chicken roaster. Commonly called Beer Can roasters.
  • The best way to roast poultry on the grill
  • For use in barbecues and ovens
  • Dishwasher safe
  • Includes rack, rack support, and basting brush


Part Number: 41333
Material: stainless steel
Weight: 0.10

$19.85

Qty


WB-7
Scrub brushes. Plastic grill scrubber. Cleans all types of cooking grids. Plastic grip handle.

Part Number: WB-7
Dimensions: 6” x 3 1/2”
Weight: 0.2

$5.96

Qty


==> All G53104 Accessories.
