Broil King Regal 20XL 959-27 Grill Parts

Highest quality replacement parts for your Broil King Regal 20XL 959-27 - Free USA shipping $49 or more* - No Sales Tax*

Broil King 959-27 owners manual and diagrams

Click the small images on the right to view Broil King 959-27 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Broil King 959-27-304004233-PartsExpS1.jpg

Broil King 959-27-304004233-PartsLstS1.jpg

Replacement grill parts for Broil King Regal 20XL (959-27)

On this page you'll find all of the parts that fit model Broil King 959-27. If the part you're shopping for isn't included below, you might find it using the category buttons on the right side of the page. For example, if your looking for a warming rack and there are none here, click the warming rack button to see all of the racks we have for Broil King grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Broil King 959-27 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Broil King model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

959-27 Burners

Click for photos

Genuine OEM Broil King stainless steel Infinity burner assembly for Broil King model 959-27. This burner assembly does not include the electrodes. Includes:

One stainless steel Infinity burner
Twin venturi with spider exclusion screens

Part Number: 10390-T501
Dimensions: 8” x 20”
Material: Stainless steel
Weight: 3.2

==> All Broil King Burners.

959-27 Cooking Grids

Click for photos

Genuine OEM Broil King cast iron cooking grid for Broil King model 959-27. Porcelain treated, flat matte finish. SOLD INDIVIDUALLY. Also replaces part# 10225-T426, which has been discontinued by the manufacturer.
Note: Dimensions are of the grid exclusive of the supports.

Part Number: 10225-T429
Dimension Front-to-Back: 14”
Dimension Side-to-Side: 12 1/4”
Material: Cast iron
Weight: 8.4

Stainless Steel cooking grid for Broil King model 959-27. 50% T45

Part Number: 10225-T424
Weight: 1.0

==> All Broil King Cooking Grids.

959-27 Heat Plates

Click for photos

Genuine OEM Broil King stainless steel Flav-R-Wave heat plate for Broil King model 959-27. Also replaces porcelain-steel part# 10222-T424, which has been discontinued by the manufacturer.

Part Number: 10222-T425
Dimension Front-to-Back: 11 1/4”
Dimension Side-to-Side: 23”
Material: Stainless steel
Weight: 3.0

==> All Broil King Heat Plates.

959-27 Igniter Components

Click for photos

Push button igniter. For single wire for grills with no side burner. Wires not included. Comes in black or grey as available from manufacturer.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-21
Weight: 0.05

Click for photos

Genuine OEM Broil King collector box and electrode assembly. Includes:

burner mounted box with mounting screw
ceramic electrode and 17” wire with round connector and protective sleeve
Use with burners 10390-T401 (14102) and 10390-T501 (14212)

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-T301
Weight: 0.05

==> All Broil King Igniter Components.

959-27 Grease Trays

Click for photos

Genuine OEM Broil King disposable grease pans. Package of 10. Each measures 4.75”x6”x1”.

Part Number: S15115
Dimensions: 4 3/4” x 6”
Material: aluminum
Weight: 0.25

==> All Broil King Grease Trays.

959-27 Regulators and Hoses

Click for photos

Genuine OEM Broil King NG gas hose.

Part Number: 10111-K45
Weight: 2.1

==> All Broil King Regulators and Hoses.

959-27 Wheels and Castors

Click for photos

Genuine OEM Broil King 8” cart wheel with a 3/8” axel hole. Also replaces part# 10892-8, and 10892-8N which have been discontinued. Is a solid rubber wheel with a plastic hub, and it has a grey sidewall stripe instead of the white found on 10892-8N.

Part Number: 10892-8NG
Dimensions: 8
Weight: 1.6

==> All Broil King Wheels and Castors.

959-27 Heat indicators and Meat Thermometers

Click for photos

Genuine OEM Broil King Heat indicator. About 2 3/8” wide and 2” high. The threaded stem is about 5 /16” diameter and 1 1/8” long.

Part Number: 10571-6
Weight: 0.12

==> All Broil King Heat indicators and Meat Thermometers.

959-27 Shelves

Click for photos

Genuine OEM Broil King Side shelf, left side.

Part Number: 10711-R562
Weight: 3.10

==> All Broil King Shelves.

959-27 Accessories

Click for photos

Cast iron smoker box with six oblong venting holes. Designed to release wood smoke. Make sure this part will fit into your grill before ordering 8 3/8” x 5 1/4” x 1 3/8”.

Part Number: 00150
Dimensions: 5 1/4” x 8 3/8”
Material: cast iron
Weight: 3.90

Click for photos

Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

Click for photos

Chrome plated rib/potatoe rack. Spaces up to 6 racks of ribs and 6 potatoes. Fits all grills. 12” x 7 1/4”.

Part Number: RR-2
Material: chrome steel
Weight: 1.0

Click for photos

Venturi Tube 12” Brush. Recommended by all grill manufacturers. Specially designed flexible brush to clean venturis of spider webs and other obstructions that can cause flashback fires. Stainless steel.

Part Number: VTC-B
Material: stainless steel
Weight: 0.3

==> All 959-27 Accessories.
