Broil King 955-78 Grill Parts

Broil King 955-78

Highest quality replacement parts for your Broil King 955-78 - Free USA shipping $49 or more* - No Sales Tax*

Broil King 955-78 owners manual and diagrams

Click the small images on the right to view Broil King 955-78 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Broil King 955-78-304442133-PartsExpS1.jpg

Broil King 955-78-304442133-PartsLstS1.gif

Broil King 955-78-304442133-PartsLstS1.jpg

Broil King 955-78-304442133-PartsLstS2.gif

Replacement grill parts to fit Broil King model: 955-78

This page shows all of the parts we know fit model Broil King 955-78. If you can't find the part you need below, click on the appropriate category button on the right side of the page. For example, if your looking for an ignitor, or other ignition components, and there are none here, click the ignition button to see what we have for Broil King grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Broil King 955-78 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Broil King model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

955-78 Burners

10390-T501

Click for photos

Genuine OEM Broil King stainless steel Infinity burner assembly for Broil King model 955-78. This burner assembly does not include the electrodes. Includes:

One stainless steel Infinity burner
Twin venturi with spider exclusion screens

Part Number: 10390-T501
Dimensions: 8” x 20”
Material: Stainless steel
Weight: 3.2

==> All Broil King Burners.

955-78 Cooking Grids

10225-T429

Click for photos

Genuine OEM Broil King cast iron cooking grid for Broil King model 955-78. Porcelain treated, flat matte finish. SOLD INDIVIDUALLY. Also replaces part# 10225-T426, which has been discontinued by the manufacturer.
Note: Dimensions are of the grid exclusive of the supports.

Part Number: 10225-T429
Dimension Front-to-Back: 14”
Dimension Side-to-Side: 12 1/4”
Material: Cast iron
Weight: 8.4

Stainless Steel cooking grid for Broil King model 955-78. 50% T45

Part Number: 10225-T424
Weight: 1.0

==> All Broil King Cooking Grids.

955-78 Heat Plates

10222-T425

Click for photos

Genuine OEM Broil King stainless steel Flav-R-Wave heat plate for Broil King model 955-78. Also replaces porcelain-steel part# 10222-T424, which has been discontinued by the manufacturer.

Part Number: 10222-T425
Dimension Front-to-Back: 11 1/4”
Dimension Side-to-Side: 23”
Material: Stainless steel
Weight: 3.0

==> All Broil King Heat Plates.

955-78 Igniter Components

10342-21

Click for photos

Push button igniter. For single wire for grills with no side burner. Wires not included. Comes in black or grey as available from manufacturer.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-21
Weight: 0.05

10342-T301

Click for photos

Genuine OEM Broil King collector box and electrode assembly. Includes:

burner mounted box with mounting screw
ceramic electrode and 17” wire with round connector and protective sleeve
Use with burners 10390-T401 (14102) and 10390-T501 (14212)

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-T301
Weight: 0.05

==> All Broil King Igniter Components.

955-78 Grease Trays

S15111

Click for photos

Stainless steel wire grease cup holder for mini bucket #S15112 which has been discontinued and replaced with mini bucket # 4673-FC. This wire holder can also be used with tin cans for easy disposal of grease.

Part Number: S15111
Material: stainless steel
Weight: 0.02

==> All Broil King Grease Trays.

955-78 Knobs and Handles

10472-K36

Click for photos

Genuine OEM Broil King control knob.

Off position D-Value: 6 o'clock
Knob diameter: 1 5/8”
Socket diameter: 5/16”
Knob shaft: 1/2”

Part Number: 10472-K36
Weight: 0.05

10239-7

Click for photos

Triangular handle washer. 1/8 in thick. Made of heat resistant compressed material.

Part Number: 10239-7
Dimensions: 1 1/2” x 1 1/4”
Weight: 0.05

==> All Broil King Knobs and Handles.

955-78 Heat indicators and Meat Thermometers

10571-6

Click for photos

Genuine OEM Broil King Heat indicator. About 2 3/8” wide and 2” high. The threaded stem is about 5 /16” diameter and 1 1/8” long.

Part Number: 10571-6
Weight: 0.12

==> All Broil King Heat indicators and Meat Thermometers.

955-78 Miscellaneous Repair Parts

S21233

Click for photos

Hinge pin clip.

Part Number: S21233
Weight: 0.01

S21362

Click for photos

REAR BURNER SPRING

Part Number: S21362
Weight: 1.0

Y-6616

Click for photos

Bolt

Part Number: Y-6616
Weight: 0.02

==> All Broil King Miscellaneous Repair Parts.

955-78 Hardware

SCREW-PHCP 6-32X1/4 TY-F JS500

Part Number: Y-12835
Weight: 1.0

==> All Broil King Hardware.

955-78 Accessories

SSST

Click for photos

Stainless steel smoker box with cover. For use with all grills. Insert moistened wood chips (not included) for your favorite smoke flavor, 8 3/4” x 3 1/2” x 1 1/2”.

Part Number: SSST
Material: stainless steel
Weight: 1.5

40259

Click for photos

15” Stainless steel tong.

Soft comfort grip
Locking mechanism

Part Number: 40259
Dimensions: 15
Material: stainless steel
Weight: 0.14

00030

Click for photos

EZ Check Gas level indicator. Accurate from -22° to 104°F. Magnetic back. Works on all sizes of tanks.

Part Number: 00030
Weight: 0.1

==> All 955-78 Accessories.
