Broil King Monarch 40 9346-67 Grill Parts

Broil King 9346-67

Highest quality replacement parts for your Broil King Monarch 40 9346-67 - Free USA shipping $49 or more* - No Sales Tax*

Broil King 9346-67 owners manual and diagrams

Click the small images on the right to view Broil King 9346-67 exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!

Broil King 9346-67-3056333232-PartsExpS1.gif

Broil King 9346-67-3056333232-PartsLstS1.gif

Broil King 9346-67-3056333232-PartsLstS2.gif

Replacement gas grill parts for Broil King Monarch 40 9346-67

All of the parts we have for Broil King 9346-67 are shown on this page. We might not show the part you need here but we may still have it, or a functional equivalent. In this case, try the category buttons on the right. For example, if your looking for a heat indicator and there are none here, click the heat indicator button to see all we have for Broil King grills. Knowing the dimensions of your existing part will help you find the right part.

To get the correct Broil King 9346-67 BBQ parts

You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
Verify your Broil King model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.

9346-67 Burners

10390-T401

Click for photos

Genuine OEM Broil King stainless steel burner and venturi assembly for Broil King model 9346-67.

Part Number: 10390-T401
Dimensions: 6 1/2” x 14 5/8”
Material: Stainless steel
Weight: 2.3

10390-E10

Click for photos

Genuine OEM Broil King Side Burner for Broil King model 9346-67. Use air shutter to adjust for LP (less air flow) or natural gas (more air flow).
This part is currently out of stock, but more are already on the way and expected to arrive late May

Part Number: 10390-E10
Weight: 0.4

==> All Broil King Burners.

9346-67 Cooking Grids

10225-T356

Click for photos

Genuine OEM Broil King cast iron cooking grid SOLD INDIVIDUALLY for Broil King model 9346-67.

Sold individually
Number required varies, check your grill
Porcelain treated, flat matte finish

Part Number: 10225-T356
Dimension Front-to-Back: 14 3/4”
Dimension Side-to-Side: 10 3/4”
Material: Cast iron
Weight: 6.1

63262

Click for photos

Cast iron cooking grids for Broil King model 9346-67. Porcelain treated, flat matte finish. Sold as a set of two (2).

Part Number: 63262
Dimension Front-to-Back: 14 3/4”
Dimension Side-to-Side: 21 1/2”
Material: matte cast iron
Weight: 15.1

==> All Broil King Cooking Grids.

9346-67 Heat Plates

10222-T325

Click for photos

Genuine OEM Broil King stainless steel Flav-R-Wave SS heat plate for Broil King model 9346-67.

Part Number: 10222-T325
Dimension Front-to-Back: 10 3/8”
Dimension Side-to-Side: 18”
Material: Stainless steel
Weight: 2.4

==> All Broil King Heat Plates.

9346-67 Igniter Components

10342-245

Click for photos

Genuine OEM Broil King electronic push-button 2-spade igniter.

Uses AAA battery (not included)
.Requires 3/4” mounting hole
Also replaces part# 10342-242 and 10342-249

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-245
Weight: 0.3

10342-T301

Click for photos

Genuine OEM Broil King collector box and electrode assembly. Includes:

burner mounted box with mounting screw
ceramic electrode and 17” wire with round connector and protective sleeve
Use with burners 10390-T401 (14102) and 10390-T501 (14212)

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-T301
Weight: 0.05

10342-T14

Click for photos

Genuine OEM Broil King 21” wire for side burner or other applications. One female spade connector, one female round connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: 10342-T14
Dimensions: 21
Weight: 0.05

==> All Broil King Igniter Components.

9346-67 Grease Trays

S15115

Click for photos

Genuine OEM Broil King disposable grease pans. Package of 10. Each measures 4.75”x6”x1”.

Part Number: S15115
Dimensions: 4 3/4” x 6”
Material: aluminum
Weight: 0.25

==> All Broil King Grease Trays.

9346-67 Knobs and Handles

10472-K431

Click for photos

10472-K431 Control knob large. Black with stainless steel BA strip.

Genuine OEM control knob.

Off position D-Value: 6 o'clock
Knob diameter: 2 1/4”
Socket diameter: 5/16”
Knob stem: 1/2”

Part Number: 10472-K431
Weight: 0.1

10239-7

Click for photos

Triangular handle washer. 1/8 in thick. Made of heat resistant compressed material.

Part Number: 10239-7
Dimensions: 1 1/2” x 1 1/4”
Weight: 0.05

PB20-60

Click for photos

S/B LID HANDLE WAGON ENCLOSER*

Part Number: PB20-60
Weight: 1.0

==> All Broil King Knobs and Handles.

9346-67 Regulators and Hoses

NG side burner hose no longer available separately.
Now sold only as entire valve assembly. Please verify your model number per the certification tag on your gas grill.

Part Number: S13467-132
Weight: 2.8

ASCPL-1

Click for photos

Five piece 3/8” natural gas quick disconnect set includes:

Part ASCPL-2 12ft vinyl 3/8” ID Sturgis hose (3/8” inside diameter outside diameter about 1/2”) with solid brass fittings
Part ASCPL-3 Sturgis brand 3/8” quick connect brass coupler
Hansen & Sturgis dust cover
plastic dust plug
Plastic 3/8 MPT Snap Tite
Suitable up to approximately 60,000 BTU.

Part Number: ASCPL-1
Weight: 3.0

==> All Broil King Regulators and Hoses.

9346-67 Wheels and Castors

10892-7G

Click for photos

Genuine OEM Broil King 7” cart wheel with 3/8” axel hole. Mini hub cap is # 00400251, sold separately.

Part Number: 10892-7G
Weight: .45

10892-15

Click for photos

Genuine OEM Broil King caster wheel; approximately 2 3/8” diameter.
This part is currently out of stock, but more are already on the way and expected to arrive late May

Part Number: 10892-15
Weight: 0.35

==> All Broil King Wheels and Castors.

9346-67 Heat indicators and Meat Thermometers

10571-6

Click for photos

Genuine OEM Broil King Heat indicator. About 2 3/8” wide and 2” high. The threaded stem is about 5 /16” diameter and 1 1/8” long.

Part Number: 10571-6
Weight: 0.12

==> All Broil King Heat indicators and Meat Thermometers.

9346-67 Miscellaneous Repair Parts

S21233

Click for photos

Hinge pin clip.

Part Number: S21233
Weight: 0.01

Y-11230

Click for photos

Cotter pin

Part Number: Y-11230
Weight: 0.01

S21420

Click for photos

Push nut 3/8

Part Number: S21420
Weight: 0.1

Y-6616

Click for photos

Bolt hex head 1 1/2” length

Part Number: Y-6616
Weight: 0.02

==> All Broil King Miscellaneous Repair Parts.

9346-67 Shelves

10184-E461

Click for photos

SHELF SUPPORT LH BLK

Part Number: 10184-E461
Weight: 1.0

SHELF SB EZ-BILT W/O BRACKET

Part Number: 10711-E563
Weight: 1.0

==> All Broil King Shelves.

9346-67 Accessories

00215

Click for photos

GrillPro Wood chips from genuine oak whiskey barrels.

All natural wood smoke flavor
Great for use in BBQ's or smokers.
170 cubic inches (2 lbs. approx) in resealable bag

Try with beef, burgers, pork, lamb, poultry, and fish.

Part Number: 00215
Weight: 2.0

40240

Click for photos

16” Stainless Steel Tong/Turner Combination. 16” multi-use tool with red soft grip rubber inserts. Can be used as a turner, tong or both. Manual lock saves on storage space.

Part Number: 40240
Dimensions: 16” x 4”
Material: chrome steel
Weight: 0.9

24764

Click for photos

Deluxe non-stick chicken and rib tumble basket. Attaches to rotisserie spit rod.

Ideal for cooking pieces of meat or vegetables
Self basting, easy to use
Locks on spit rod with thumb screw (supplied)
6 1/2” x 10” long

Part Number: 24764
Dimensions: 6 1/2” x 10”
Weight: 1.1

00030

Click for photos

GrillPro EZ Check Gas level indicator. Accurate from -22° to 104°F. Magnetic back. Works on all sizes of tanks.

This tank gauge will monitor your propane level, while you grill, and let's you know when you're running low on gas.

The magnetic tank gauge offers fast, accurate propane level monitoring for any size LP tank. The magnetic backing makes it easy to attach, remove, and reuse across multiple tanks—perfect for grilling, camping, patio heaters, and more

Part Number: 00030
Weight: 0.1

41333

Click for photos

Stainless steel chicken roaster. Commonly called Beer Can roasters.

The best way to roast poultry on the grill
For use in barbecues and ovens
Dishwasher safe
Includes rack, rack support, and basting brush

Part Number: 41333
Material: stainless steel
Weight: 0.10

CGT

Click for photos

Cannon Grill Towel.

Part Number: CGT
Dimensions: 16” x 25”
Weight: 0.30

==> All 9346-67 Accessories.
