Bakers & Chefs 9803S Grill Parts

Bakers & Chefs logo



Bakers & Chefs 9803S



Highest quality replacement parts for your Bakers & Chefs 9803S - Free USA shipping $49 or more* - No Sales Tax*



Bakers & Chefs 9803S owners manual and diagrams
Click the small images on the right to view Bakers & Chefs 9803S exploded parts diagrams and parts lists. Owners manual not available. If you have a manual you're willing to share, please click here to send us an email with the attached manual. Thank You!



Bakers & Chefs 9803S-30195534-PartsExpS1.jpg  Bakers & Chefs 9803S-30195534-PartsLstS1.gif  Bakers & Chefs 9803S-30195534-PartsLstS1.jpg

Replacement grill parts for the Bakers & Chefs model: 9803S
On this page you'll find all of the parts that fit model Bakers & Chefs 9803S. If the part you need is not shown below, try clicking the appropriate category button on the right side of the page. For example, if your looking for a warming rack and there are none here, click the warming rack button to see all of the racks we have for Bakers & Chefs grills. You will need to know the dimensions of your existing grids to help you find the right part.

To get the correct Bakers & Chefs 9803S BBQ parts
  • You should measure your existing parts and compare them to what we show here. This is best done with them removed from the grill.
  • Verify your Bakers & Chefs model number by checking the CSA appliance tag on your grill to make sure you have the correct model number. Do not rely solely on the owners manual as these are frequently mixed up at retail stores when the grills are assembled. You'd be surprised at how many folks have the wrong owners manual.



9803S Burners

CISC
Click for photos
Cast iron burner for Bakers & Chefs model 9803S.

Part Number: CISC
Dimensions: 15 3/4” x 4 3/4”
Material: cast iron
Weight: 5.0

$42.97

Qty


29251-CSS-X3
Click for photos
Cast stainless steel burner for Bakers & Chefs model 9803S. Tired of changing out rusted cast iron burners? Far superior to the cast iron and brass versions, this burner will probably outlast your grill. Designed to replace cast iron and brass burners of same design..

Part Number: 29251-CSS-X3
Dimensions: 16” x 4 5/8”
Material: cast stainless steel
Weight: 10.05

$258.70

Qty


29251-CSS
Click for photos
Cast stainless steel burner for Bakers & Chefs model 9803S. Tired of changing out rusted cast iron burners? Far superior to the cast iron and brass versions, this burner will probably outlast your grill. Designed to replace cast iron and brass burners of same design..

Part Number: 29251-CSS
Dimensions: 16” x 4 5/8”
Material: cast stainless steel
Weight: 3.35

$86.68

Qty


29251-X3
Cast iron burners for Bakers & Chefs model 9803S. SET OF THREE(3).

Part Number: 29251-X3
Dimensions: 15 3/4” x 4 3/4”
Material: cast iron
Weight: 19.2

$101.84

Qty


CISC-X3
Click for photos
Cast iron burner for Bakers & Chefs model 9803S.

Part Number: CISC-X3
Dimensions: 15 3/4” x 4 3/4”
Material: cast iron
Weight: 15.0

$92.94

Qty


==> All Bakers & Chefs Burners.






9803S Cooking Grids

CLS9151
Click for photos

Premium quality stainless steel cooking grid for Bakers & Chefs model 9803S. Our USA-made premium stainless grids are simply the best obtainable. We have them manufactured here in the USA to our specifications and standards, which are high. Of course, they're not available anywhere else.

Unlike the standard issue stainless grids generally found today, which are typically low grade stainless and sometimes hollow, or coated carbon steel, our premium grids are made from solid high quality stainless steel rods. If you're looking for the best, you've found it.

  • 304 commercial grade stainless steel
  • 1/4” diameter solid stainless rods
  • Dimensions: 18 7/8” x 10”
  • Made in USA.
  • Sold individually.


Part Number: CLS9151
Dimension Front-to-Back: 18 7/8”
Dimension Side-to-Side: 10”
Material: solid stainless steel
Weight: 4.0

$38.34

Qty


==> All Bakers & Chefs Cooking Grids.






9803S Heat Plates

CLA1721
Click for photos
Replacement steel Flame Tamer for Bakers & Chefs model 9803S. For many models, can also be used to replace ceramic flame tamers and the rack that holds them. Made in USA.

Part Number: CLA1721
Dimension Front-to-Back: 16 7/8”
Dimension Side-to-Side: 9 3/4”
Material: carbon steel
Weight: 3.5

$23.22

Qty


CLA2721
Stainless steel Flame Tamer for Bakers & Chefs model 9803S. For many models, can also be used to replace ceramic flame tamers and the rack that holds them. Made in USA.

Part Number: CLA2721
Dimension Front-to-Back: 16 3/4”
Dimension Side-to-Side: 9 3/4”
Material: stainless steel
Weight: 2.4

$49.99

Qty


SET OF THREE/3 PACK Stainless steel Flame Tamer for Bakers & Chefs model 9803S. For many models, can also be used to replace ceramic flame tamers and the rack that holds them. Made in USA.

Part Number: CLA2721-X3
Dimension Front-to-Back: 16 3/4”
Dimension Side-to-Side: 9 3/4”
Material: stainless steel
Weight: 7.2

$129.46

Qty


==> All Bakers & Chefs Heat Plates.






9803S Igniter Components

IG-17B
Click for photos
Stainless steel collector box and ceramic electrode with round connector. Includes mounting nuts and washer.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-17B
Weight: 0.11

$10.81

Qty


IGEIB4-B
Click for photos
Battery powered push button igniter.
  • Has four (4) spade type male connectors.
  • Uses 1 AAA battery (not supplied)
  • Requires 3/4” or 13/16” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IGEIB4-B
Weight: 0.3

$31.52

Qty


IG-7B
Click for photos
20” igniter wire with female spade and round connector.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-7B
Weight: 0.02

$4.47

Qty


IG-30B
Click for photos
46” Wire with female spade connectors and square plastic connectors.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-30B
Dimensions: 46
Weight: 0.1

$7.10

Qty


IG-48B
Click for photos
16” Universal Ignitor Wire

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: IG-48B
Dimensions: 16
Weight: 0.05

$6.00

Qty


TS-IG4010
Click for photos
Push-button electronic igniter with four (4) spade connectors. Black cap. Uses one AAA battery (not included). Requires a 3/4” mounting hole.

For more information about ignition systems and components, please see article Ignition 101 in our help center.



Part Number: TS-IG4010
Weight: 0.2

$18.49

Qty


==> All Bakers & Chefs Igniter Components.






9803S Knobs and Handles

03430
Click for photos
Black control knob (Some originals may have been chrome).
  • Off position D-Value: 12 o'clock
  • Knob diameter: 2 3/16”
  • Socket diameter: 6mm
  • Knob shaft: None


Part Number: 03430
Dimensions: 2 3/16” x 2 3/16”
Material: plastic
Weight: 0.2

$10.87

Qty


==> All Bakers & Chefs Knobs and Handles.






9803S Accessories

FS-1
Click for photos
Fish Spatula. Stainless steel fish spatula with genuine rosewood handle. 18 1/2”. 10” spatula width.

Part Number: FS-1
Dimensions: 18 1/2
Material: stainless steel
Weight: 1.0

$17.27

Qty


BB-5
Click for photos
Basting brush with angled oak handle. 18” overall length.

Part Number: BB-5
Dimensions: 18
Weight: 0.8

$8.84

Qty


WB-3
18” long wood handle brass bristle grid brush with scraper and leather hang strap.

Part Number: WB-3
Dimensions: 18
Weight: 0.59

$12.50

Qty


==> All 9803S Accessories.
