Alfresco ALXE-56BFGC Grill Parts

ALF2-290-0038-X3 BBQ U Main Burner Assembly for Alfresco model ALXE-56BFGC. SET OF THREE (3). Fits ALX2 and ALXE series Alfresco grills.

NOTE: This burner replaces original Alfresco burner part# 290-0038.

Part Number: ALF2-290-0038-X3 (Replaces Alfresco ALF-290-0038-X3)
Dimensions: 18 1/8” x 7 13/16”
Material: stainless steel
Weight: 6.0

ALF2-290-0038 BBQ U Main Burner Assembly for Alfresco model ALXE-56BFGC. Fits ALX2 and ALXE series Alfresco grills.

NOTE: This burner replaces original Alfresco burner part# 290-0038.

Part Number: ALF2-290-0038 (Replaces Alfresco ALF-290-0038)
Dimensions: 18 1/8” x 7 13/16”
Material: stainless steel
Weight: 2.0

ALF2-290-0124-X3 Premium Stainless Steel BBQ Grill / Cooking Grids for Alfresco model ALXE-56BFGC. SET OF THREE (3). Fits Alfresco ALX2-56 and ALXE-56 series grills.

• Made in USA
• 304 commercial grade stainless steel
• 3/8” Solid stainless rods
• Sold as a set of three (3) 12 3/4” wide grids

NOTE: This Cooking grid replaces original Alfresco BBQ Grill 12 3/4” wide part# 290-0124.

Part Number: ALF2-290-0124-X3 (Replaces Alfresco ALF-290-0124-X3)
Dimension Front-to-Back: 18 3/4”
Dimension Side-to-Side: 37 1/2”
Material: stainless steel
Weight: 27.5

ALF2-290-0124 Premium Stainless Steel BBQ Grill / Cooking Grid for Alfresco model ALXE-56BFGC.

• Made in USA
• 304 commercial grade stainless steel
• 3/8” Solid stainless rods
• Sold individually

Fits Alfresco:

• ALX2-30, ALX2-42 and ALX2-56 series grills
• ALXE-30, ALXE-42 and ALXE-56 series grills

NOTE: This Cooking grid replaces original Alfresco BBQ Grill 12 3/4” wide part# 290-0124.

Part Number: ALF2-290-0124 (Replaces Alfresco ALF-290-0124)
Dimension Front-to-Back: 18 3/4”
Dimension Side-to-Side: 12 3/4”
Material: stainless steel
Weight: 9.80

ALF2-100-1894-X3 Stainless steel BBQ briquette tray. SET OF THREE (3). Fits 2011 and later Alfresco ALX2-30, ALX2-42 and ALX2-56 series grills.

• Made in USA
• Heavy gauge 304 stainless steel
• Set of three (3). Also available individually and in a set of two (2).

Note: This part replaces original Alfresco Briquette Tray Base part# 100-1894.

Part Number: ALF2-100-1894-X3 (Replaces Alfresco ALF-100-1894-X3)
Dimension Front-to-Back: 17 13/16”
Dimension Side-to-Side: 12 7/8”
Material: stainless steel
Weight: 4.5

ALF2-100-1894 Stainless steel BBQ briquette tray. Fits 2011 and later Alfresco ALX2-30, ALX2-42 and ALX2-56 series grills.

• Made in USA
• Heavy gauge 304 stainless steel
• Sold individually. Also available in sets of two & three.

Note: This part replaces original Alfresco Briquette Tray Base part# 100-1894.

Part Number: ALF2-100-1894 (Replaces Alfresco ALF-100-1894)
Dimension Front-to-Back: 17 13/16”
Dimension Side-to-Side: 12 7/8”
Material: stainless steel
Weight: 1.5

ALF2-210-0189 Electrode, L Shaped Main burner. Fits Alfresco AGBQ, ALX2 and ALXE series grill models. Used with Main ”U” burner and smoker burner. Not for use on SearZone burner.

Note: This part replaces original Alfresco Electrode part# 210-0189.

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: ALF2-210-0189 (Replaces Alfresco ALF-210-0189)
Weight: 0.15

Stainless Ignitor Shield for Alfresco

For more information about ignition systems and components, please see article Ignition 101 in our help center.

Part Number: IG-50B
Weight: 0.15

Universal premium quality stainless steel warming rack. You simply can't buy a better quality warming rack than this, which weighs in at almost 5lbs of solid 304 grade stainless steel. This super heavy-duty warming rack was made to replace the porcelain coated steel racks found on BBQ grills made by The Great Outdoors Grill Company, but can be used in any grill wide enough inside for the 24” rack.

• Far superior to the original porcelain coated steel rack
• Rests on your existing cooking grids.
• Solid 1/4” 304 stainless steel rods.
• Stands 3.75 inches tall.
• Made in USA.

NOTE: Before ordering this universal rack, please verify your grill has enough space to accommodate it. What's required?

• Your grill needs to be at least 24” wide on the inside . The warming rack is 6.25” front to back and stands 3.75” tall.
• Notice the shape of the warming rack. Determine if the lid of your grill can easily close with the warming rack inside.

  Part Number: CLA-WS0040
  Dimensions: 6 1/4” x 22 7/8”
  Material: stainless steel
  Weight: 4.8

Universal four piece mini thermometer set. Great gift idea.

• 2 calibrated for steak, and 2 for chicken
• Mini thermometers for testing doneness of individual cuts of meat
• Silicone bezels for easy removal when hot
• Always use caution when handling hot objects

Part Number: 11381
Weight: .25

Ceramic briquette. Briquettes collect heat and radiate it to the food on the cooking grids. They also help prevent flare-ups and keep the flames from actually touching the food allowing for more efficient and uniform heat distribution.

Designed primarily to work in stainless steel trays on Lynx, Alfresco, and other brand grills, these briquettes can be and often are used on any grill with an ordinary grate to support them.

• Individual briquettes measure 2” x 2”
• Set includes 28 ceramic briquettes
• More than one set may be required per grill model

Part Number: BQLYX
Dimensions: 2” x 2”
Material: ceramic
Weight: 4.0

Ceramic briquettes 48 pieces. Fits briquette trays 94751, 92571 and and simular trays. Works in all grills designed for briquettes or lava rock. Each briquette measures 2” x 2” x 3/4".

Part Number: 41648
Dimensions: 2” x 2”
Material: ceramic
Weight: 7.5

Stainless steel smoker box with cover. For use with all grills. Insert moistened wood chips (not included) for your favorite smoke flavor, 8 3/4” x 3 1/2” x 1 1/2”.


Part Number: SSST
Material: stainless steel
Weight: 1.5

5-piece unique tennis oriented utensil set. Constructed of heavy stainless steel with ”tennis grips” on each utensil. Includes yellow tennis ball style salt & pepper shakers, along with spatula, fork and tong.

Makes a nice gift.for tennis-minded folks

Part Number: US10
Weight: 5.00

Deluxe non-stick flat spit basket. Attaches to 3/8” rotisserie rod with adjustable lid to secure food. 16”x7.5”x2”
WARNING: Before ordering, please verify that your rotisserie spit rod can fit through the .48 inch x .48 squared mounting holes. Our spit rod part numbers SR-5, SR-8 and SR-43 do fit.

Part Number: 24785
Dimensions: 7 1/2” x 16”
Weight: 1.5

Stainless steel jalapeno pepper tray.Cook all the heat from a jalapeño and you’re left with a fabulous taste of the southwest that leaves your taste buds singing for hours.

• Constructed of 304 stainless steel
• Measures 9-1/2” x 6-1/2”
• Holds up-to 24 jalapeño peppers
• American-Made

Part Number: JPT
Dimensions: 14 1/4” x 6”
Material: stainless steel
Weight: 0.6

Scrub brushes. Plastic grill scrubber. Cleans all types of cooking grids. Plastic grip handle.

Part Number: WB-7
Dimensions: 6” x 3 1/2”
Weight: 0.2
